RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
975
innovators for industry
Code
HIGH
(hex)
0E As of scan system firmware  206x.
SetControlDefinitionMode
SetControlDefinitionMode causes the scan system to transmit information about a specific
tuning (or the corresponding control algorithm) over the selected status channel.
See also “On SetMode, SetControlDefinitionMode and SetEchoMode”, Seite 982.
Code
LOW
(hex)
Data type transmitted by the scan system
00
01
02
03
As of scan system firmware  206x.
Tuning number
16-bit
protocol
20-bit
protocol
Bit #15
(MSB)
Bit #19
(MSB)
= 0: Tuning available.
= 1: Tuning not available.
Bit #4
…
Bit #14
Bit #8
…
Bit #18
Reserved.
Bit #0
…
Bit #3
Bit #4
…
Bit #7
Tuning type
= 0: Vector tuning.
= 1: Jump tuning.
= 2: Reserved.
= 3: Reserved.
= 4: As of scan system firmware  5050.
SCANahead servo control.
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
