High-resolution timer (HRTIM) RM0440
1026/2126 RM0440 Rev 4
27.5.48 HRTIM timer x fault register (HRTIM_FLTxR) (x = A to F)
Address offset: Block A: 0x0E8
Address offset: Block B: 0x168
Address offset: Block C: 0x1E8
Address offset: Block D: 0x268
Address offset: Block E: 0x2E8
Address offset: Block F: 0x368
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
FLT
LCK
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rwo
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
FLT6
EN
FLT5
EN
FLT4
EN
FLT3
EN
FLT2
EN
FLT1
EN
rw rw rw rw rw rw
Bit 31 FLTLCK: Fault sources lock
0: FLT1EN..FLT6EN bits are read/write
1: FLT1EN..FLT6EN bits are read only
The FLTLCK bit is write-once. Once it has been set, it cannot be modified till the next system reset.
Bits 30:6 Reserved, must be kept at reset value.
Bit 5 FLT6EN: Fault 6 enable
0: Fault 6 input ignored
1: Fault 6 input is active and disables HRTIM outputs
Bit 4 FLT5EN: Fault 5 enable
0: Fault 5 input ignored
1: Fault 5 input is active and disables HRTIM outputs
Bit 3 FLT4EN: Fault 4 enable
0: Fault 4 input ignored
1: Fault 4 input is active and disables HRTIM outputs
Bit 2 FLT3EN: Fault 3 enable
0: Fault 3 input ignored
1: Fault 3 input is active and disables HRTIM outputs
Bit 1 FLT2EN: Fault 2 enable
0: Fault 2 input ignored
1: Fault 2 input is active and disables HRTIM outputs
Bit 0 FLT1EN: Fault 1 enable
0: Fault 1 input ignored
1: Fault 1 input is active and disables HRTIM outputs
