RM0440 Rev 4 1049/2126
RM0440 High-resolution timer (HRTIM)
1083
27.5.65 HRTIM timer external event control register 3 (HRTIM_EECR3)
Address offset: 0x3B8
Reset value: 0x0000 0000
Bits 4:3 EE6SNS[1:0]: External event 6 sensitivity
Refer to EE1SNS[1:0] description.
Bit 2 EE6POL: External event 6 polarity
Refer to EE1POL description.
Bits 1:0 EE6SRC[1:0]: External event 6 source
Refer to EE1SRC[1:0] description.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
EEVSD[1:0] Res. Res. EE10F[3:0] Res. Res. EE9F[3:0] Res. Res.
rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
EE8F[3:0] Res. Res. EE7F[3:0] Res. Res. EE6F[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:30 EEVSD[1:0]: External event sampling clock division
This bitfield indicates the division ratio between the timer clock frequency (f
HRTIM
) and the external
event signal sampling clock (f
EEVS
) used by the digital filters.
00: f
EEVS
=f
HRTIM
01: f
EEVS
=f
HRTIM
/ 2
10: f
EEVS
=f
HRTIM
/ 4
11: f
EEVS
=f
HRTIM
/ 8
Bits 29:28 Reserved, must be kept at reset value.
Bits 27:24 EE10F[3:0]: External event 10 filter
Refer to EE6F[3:0] description.
Bits 23:22 Reserved, must be kept at reset value.
Bits 21:18 EE9F[3:0]: External event 9 filter
Refer to EE6F[3:0] description.
Bits 17:16 Reserved, must be kept at reset value.
Bits 15:12 EE8F[3:0]: External event 8 filter
Refer to EE6F[3:0] description.
Bits 11:10 Reserved, must be kept at reset value.
