RM0440 Rev 4 1333/2126
RM0440 General-purpose timers (TIM2/TIM3/TIM4/TIM5)
1343
29.5.23 TIMx capture/compare register 4 (TIMx_CCR4)(x = 3, 4)
Address offset: 0x040
Reset value: 0x0000 0000
Bits 31:0 CCR3[31:0]: Capture/compare 3 value
If channel CC3 is configured as output:
CCR3 is the value to be loaded in the actual capture/compare 3 register (preload value). It is
loaded permanently if the preload feature is not selected in the TIMx_CCMR3 register (bit
OC3PE). Else the preload value is copied in the active capture/compare 3 register when an
update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on tim_oc3 output.
Non-dithering mode (DITHEN = 0)
The register holds the compare value.
Dithering mode (DITHEN = 1)
The register holds the integer part in CCR3[31:4]. The CCR3[3:0] bitfield contains the
dithered part.
If channel CC3 is configured as input:
CCR3 is the counter value transferred by the last input capture 3 event (tim_ic3). The
TIMx_CCR3 register is read-only and cannot be programmed.
Non-dithering mode (DITHEN = 0)
The register holds the capture value.
Dithering mode (DITHEN = 1)
The register holds the capture in CCR3[31:0]. The CCR3[3:0] bits are reset.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CCR4[19:16]
rw rw rw rw
1514131211109876543210
CCR4[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
