General-purpose timers (TIM2/TIM3/TIM4/TIM5) RM0440
1336/2126 RM0440 Rev 4
29.5.26 TIMx timer input selection register (TIMx_TISEL)(x = 2 to 5)
Address offset: 0x05C
Reset value: 0x0000 0000
Bits 7:6 IPOS[1:0]: Index positioning
In quadrature encoder mode (SMS[3:0] = 0001, 0010, 0011, 1110, 1111), this bit indicates in
which AB input configuration the Index event resets the counter.
00: Index resets the counter when AB = 00
01: Index resets the counter when AB = 01
10: Index resets the counter when AB = 10
11: Index resets the counter when AB = 11
In directional clock mode or clock plus direction mode (SMS[3:0] = 1010, 1011, 1100, 1101),
these bits indicates on which level the Index event resets the counter. In bidirectional clock
mode, this applies for both clock inputs.
x0: Index resets the counter when clock is 0
x1: Index resets the counter when clock is 1
Note: IPOS[1] bit is not significant
Bit 5 FIDX: First index
This bit indicates if the first index only is taken into account
0: Index is always active
1: the first Index only resets the counter
Bits 4:3 Reserved, must be kept at reset value.
Bits 2:1 IDIR[1:0]: Index direction
This bit indicates in which direction the Index event resets the counter.
00: Index resets the counter whatever the direction
01: Index resets the counter when up-counting only
10: Index resets the counter when down-counting only
11: Reserved
Note: The IDR[1:0] bitfield must be written when IE bit is reset (index disabled).
Bit 0 IE: Index enable
This bit indicates if the Index event resets the counter.
0: Index disabled
1: Index enabled
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. TI4SEL[3:0] Res. Res. Res. Res. TI3SEL[3:0]
rw rw rw rw rw rw rw rw
1514131211109876543210
Res. Res. Res. Res. TI2SEL[3:0] Res. Res. Res. Res. TI1SEL[3:0]
rw rw rw rw rw rw rw rw
Bits 31:28 Reserved, must be kept at reset value.
