FD controller area network (FDCAN) RM0440
1968/2126 RM0440 Rev 4
R1 Bit 31
ANMF
Accepted non-matching frame
Acceptance of non-matching frames may be enabled via RXGFC[ANFS] and
RXGFC[ANFE].
– 0: Received frame matching filter index FIDX
– 1: Received frame did not match any Rx filter element
R1 Bits 30:24
FIDX[6:0]
Filter index
0-27=Index of matching Rx acceptance filter element (invalid if ANMF = 1).
Range is 0 to RXGFC[LSS] - 1 or RXGFC[LSE] - 1.
R1 Bit 21
FDF
FD format
– 0: Standard frame format
– 1: FDCAN frame format (new DLC-coding and CRC)
R1 Bit 20
BRS
Bit rate switch
– 0: Frame received without bit rate switching
– 1: Frame received with bit rate switching
R1 Bits 19:16
DLC[3:0]
Data length code
– 0-8: Classic CAN + CAN FD: received frame has 0-8 data bytes
– 9-15: Classic CAN: received frame has 8 data bytes
– 9-15: CAN FD: received frame has 12/16/20/24/32/48/64 data bytes
R1 Bits 15:0
RXTS[15:0]
Rx timestamp
Timestamp Counter value captured on start of frame reception. Resolution depending
on configuration of the Timestamp Counter Prescaler TSCC[TCP].
R2 Bits 31:24
DB3[7:0]
Data Byte 3
R2 Bits 23:16
DB2[7:0]
Data Byte 2
R2 Bits 15:8
DB1[7:0]
Data Byte 1
R2 Bits 7:0
D[7:0]
Data Byte 0
R3 Bits 31:24
DB7[7:0]
Data Byte 7
R3 Bits 23:16
DB6[7:0]
Data Byte 6
R3 Bits 15:8
DB5[7:0]
Data Byte 5
R3 Bits 7:0
DB4[7:0]
Data Byte 4
...
...
Rn Bits 31:24
DBm[7:0]
Data Byte m
Table 397. Rx FIFO element description (continued)
Field Description
