RM0440 FD controller area network (FDCAN)
2008
44.4.25 FDCAN Rx FIFO 1 acknowledge register (FDCAN_RXF1A)
Address offset: 0x009C
Reset value: 0x0000 0000
44.4.26 FDCAN Tx buffer configuration register (FDCAN_TXBC)
Address offset: 0x00C0
Reset value: 0x0000 0000
Bits 17:16 F1PI[1:0]: Rx FIFO 1 put index
Rx FIFO 1 write index pointer, range 0 to 2.
Bits 15:10 Reserved, must be kept at reset value.
Bits 9:8 F1GI[1:0]: Rx FIFO 1 get index
Rx FIFO 1 read index pointer, range 0 to 2.
Bits 7:4 Reserved, must be kept at reset value.
Bits 3:0 F1FL[3:0]: Rx FIFO 1 fill level
Number of elements stored in Rx FIFO 1, range 0 to 3.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. F1AI[2:0]
rw rw rw
Bits 31:3 Reserved, must be kept at reset value.
Bits 2:0 F1AI[2:0]: Rx FIFO 1 acknowledge index
After the Host has read a message or a sequence of messages from Rx FIFO 1 it has to write
the buffer index of the last element read from Rx FIFO 1 to F1AI. This sets the Rx FIFO 1 get
index RXF1S[F1GI] to F1AI + 1 and update the FIFO 1 Fill Level RXF1S[F1FL].
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. TFQM Res. Res. Res. Res. Res. Res. Res. Res.
rw
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
