Flexible static memory controller (FSMC) RM0440
556/2126 RM0440 Rev 4
PSRAM chip select counter register (FMC_PCSCNTR)
Address offset: 0x20
Reset value: 0x0000 0000
This register contains the PSRAM chip select counter value for Synchronous and
Asynchronous modes. The chip select counter is common to all banks and can be enabled
separately on each bank. During PSRAM read or write accesses, this value is loaded into a
timer which is decremented while the NE signal is held low. When the timer reaches 0, the
PSRAM controller splits the current access, toggles NE to allow PSRAM device refresh, and
restarts a new access. The programmed counter value guarantees a maximum NE pulse
width (t
CEM
) as specified for PSRAM devices. The counter is reloaded and starts
decrementing each time a new access is started by a transition of NE from high to low.
h
Bits 15:8 DATAST[7:0]: Data-phase duration.
These bits are written by software to define the duration of the data phase (refer to Figure 54 to
Figure 66), used in asynchronous SRAM, PSRAM and NOR Flash memory accesses:
0000 0000: Reserved
0000 0001: DATAST phase duration = 1 × HCLK clock cycles
0000 0010: DATAST phase duration = 2 × HCLK clock cycles
...
1111 1111: DATAST phase duration = 255 × HCLK clock cycles (default value after reset)
Bits 7:4 ADDHLD[3:0]: Address-hold phase duration.
These bits are written by software to define the duration of the address hold phase (refer to
Figure 63 to Figure 66), used in asynchronous multiplexed accesses:
0000: Reserved
0001: ADDHLD phase duration = 1 × HCLK clock cycle
0010: ADDHLD phase duration = 2 × HCLK clock cycle
...
1111: ADDHLD phase duration = 15 × HCLK clock cycles (default value after reset)
Note: In synchronous NOR Flash accesses, this value is not used, the address hold phase is always
1 Flash clock period duration.
Bits 3:0 ADDSET[3:0]: Address setup phase duration.
These bits are written by software to define the duration of the address setup phase in HCLK cycles
(refer to Figure 54 to Figure 66), used in asynchronous accesses:
0000: ADDSET phase duration = 0 × HCLK clock cycle
...
1111: ADDSET phase duration = 15 × HCLK clock cycles (default value after reset)
Note: In synchronous accesses, this value is not used, the address setup phase is always 1 Flash
clock period duration. In muxed mode, the minimum ADDSET value is 1.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
CNTB4EN CNTB3EN CNTB2EN CNTB1EN
rw rw rw rw
1514131211109876543210
CSCOUNT[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
