ST STM32G471 User Manual

Flexible static memory controller (FSMC) RM0440
568/2126 RM0440 Rev 4
Attribute memory space timing register (FMC_PATT)
Address offset: 0x8C
Reset value: 0xFCFC FCFC
The FMC_PATT read/write register contains the timing information for NAND Flash memory
bank. It is used for 8-bit accesses to the attribute memory space of the NAND Flash for the
last address write access if the timing must differ from that of previous accesses (for
Ready/Busy management, refer to Section 19.7.5: NAND Flash prewait functionality).
Bits 7:0 MEMSET[7:0]: Common memory x setup time
Defines the number of HCLK (+1) clock cycles to set up the address before the command
assertion (NWE, NOE), for NAND Flash read or write access to common memory space on
socket x:
0000 0000: 1 HCLK cycle
1111 1110: 255 HCLK cycles
1111 1111: reserved
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
ATTHIZ[7:0] ATTHOLD[7:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
ATTWAIT[7:0] ATTSET[7:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:24 ATTHIZ[7:0]: Attribute memory data bus Hi-Z time
Defines the number of HCLK clock cycles during which the data bus is kept in Hi-Z after the
start of a NAND Flash write access to attribute memory space on socket. Only valid for writ
transaction:
0000 0000: 0 HCLK cycle
1111 1110: 255 HCLK cycles
1111 1111: reserved.
Bits 23:16 ATTHOLD[7:0]: Attribute memory hold time
Defines the number of HCLK clock cycles for write access and HCLK (+2) clock cycles for
read access during which the address is held (and data for write access) after the command
deassertion (NWE, NOE), for NAND Flash read or write access to attribute memory space
on socket:
0000 0000: reserved
0000 0001: 1 HCLK cycle for write access / 3 HCLK cycles for read access
1111 1110: 254 HCLK cycles for write access / 256 HCLK cycles for read access
1111 1111: reserved.
Bits 15:8 ATTWAIT[7:0]: Attribute memory wait time
Defines the minimum number of HCLK (+1) clock cycles to assert the command (NWE,
NOE), for NAND Flash read or write access to attribute memory space on socket x. The
duration for command assertion is extended if the wait signal (NWAIT) is active (low) at the
end of the programmed value of HCLK:
0000 0000: reserved
0000 0001: 2 HCLK cycles (+ wait cycle introduced by deassertion of NWAIT)
1111 1110: 255 HCLK cycles (+ wait cycle introduced by deasserting NWAIT)
1111 1111: reserved.
