2-22 Internal Architecture
AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996
Internal Snooping The processor automatically snoops its instruction cache dur-
ing read or write misses to its data cache, and it snoops its data
cache during read misses to its instruction cache. It does this to
detect the presence of self-modifying code. Table 2-4 summa-
rizes the actions taken during this internal snooping.
Table 2-4. Snoop Action
Origin of
Snoop
Type of Access
Snooping Action
Instructions Data
Instruction
Cache
Prefetch
Cache
Data
Cache
Store
Buffer
Writeback
Buffers
External Inquire Cycle
yes
1
yes
yes
1
no
yes
1
Internal
Instruction
Cache
Read
Miss
— —
yes
2
yes
2
yes
2
Read
Hit
— —nonono
Data
Cache
Read
Miss
yes
3
yes
3
— — —
Read
Hit
no no
— — —
Write
Miss
yes
4
yes
4
— — —
Write
Hit
no no
— — —
Notes:
1. The processor’s response to a snoop hit depends on the state of the INV input signal and the state of the cache line as follows:
For instructions if INV is negated, the line remains invalid or shared, but if INV is asserted, the line is invalidated. For data if INV is
negated, valid lines remain in or transition to the shared state, a modified data cache line is written back before the line is marked
shared (with HITM
asserted), invalid lines remain invalid.
For data if INV is asserted, the line is marked invalid. Modified lines are written back before invalidation.
2. If the snoop hits a line in the data cache, store buffer or writeback buffer, the line is written back (if modified) and invalidated.
Then the instruction-cache read is performed again. If the line is modified, a copy of the writeback data is passed directly to the
instruction cache, thus avoiding a line-fill bus cycle after the writeback bus cycle.
3. If the snoop hits a line in the instruction cache, prefetch cache, or line-fill buffer, the line stays valid and the data-cache read is
performed again, but as a single, non-cacheable read.
4. If the snoop hits a line in the instruction cache, prefetch cache, or line-fill buffer, the line is invalidated and the data-cache write is
performed.
— Not applicable.

AMD K5 Specifications

General

Manufacturer	AMD
Model	K5
Architecture	x86
Microarchitecture	K5
Introduction Year	1996
Clock Speed	75 - 133 MHz
Core Count	1
Socket	Socket 7
Core stepping	SSA/5, 5k86
Voltage	3.3V
Transistors	4.3 million
L1 Cache	8 KB (data) + 16 KB (instruction)
FSB	50 MHz to 66 MHz
Process Technology	350 nm
