3-32 Software Environment and Extensions

AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996

3.3.4 RDTSC

mnemonic opcode description

RDTSC 0F31 Read time stamp counter

Privilege: Selectable by TSD bit in CR4

Registers Affected: EAX, EDX

Flags Affected: none

Exceptions Generated: Real, Virtual-8086 mode—Invalid Opcode

Protected mode—GP (0) if CPL not = 0 when CR4.TSD = 1

The processor’s 64-bit time stamp counter (TSC) increments on each processor clock.

In Real or Protected mode, the counter can be read with the RDMSR instruction and

written with the WRMSR instruction when CPL = 0. However, in Protected mode the

RDTSC instruction can be used to read the counter at privilege levels higher than

CPL = 0.

The required privilege level for using the RDTSC instruction is determined by the

Time Stamp Disable (TSD) bit in CR4, as follows:

■ CPL = 0—Set the TSD bit in CR4 to 1

■ Any CPL—Clear the TSD bit in CR4 to 0

The RDTSC instruction reads the counter value into the EDX and EAX registers as

follows:

■ EDX—Upper 32 bits of TSC

■ EAX—Lower 32 bits of TSC

The following example shows how the RDTSC instruction can be used. After this

code is executed, EAX and EDX contain the time required to execute the RDTSC

instruction.

mov ecx,10h ;Time Stamp Counter Access via MSRs

mov eax,00000000h ;Initialize the Counter to zero

db 0Fh, 30h ;WRMSR

db 0Fh, 31h ;RDTSC
