3-16 Software Environment and Extensions
AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996
Table 3-5A through Table 3-5E shows the effects, in various
x86-processor modes, of instructions that read or write the IF
and VIF flag. The column headings in this table include the fol-
lowing values:
■ PE—Protection Enable bit in CR0 (bit 0)
■ VM—Virtual-8086 Mode bit in EFLAGS (bit 17)
■ VME—Virtual Mode Extensions bit in CR4 (bit 0)
■ PVI—Protected-mode Virtual Interrupts bit in CR4 (bit 1)
■ IOPL—I/O Privilege Level bits in EFLAGS (bits 13–12)
■ Handler CPL—Code Privilege Level of the interrupt
handler
■ GP(0)—General-protection exception, with error code = 0
■ IF—Interrupt Flag bit in EFLAGS (bit 9)
■ VIF—Virtual Interrupt Flag bit in EFLAGS (bit 19)
Table 3-5A. Instructions that Modify the IF or VIF Flags—Real Mode
TYPE PE VM VME PVI IOPL GP(0) IF VIF
CLI 0000—NoIF ← 0—
STI 0000—NoIF ← 1—
PUSHF 0000—NoPushed—
POPF 0000—NoPopped—
IRET 0000—NoPopped—
Notes:
— Not applicable.
