7-14 Test and Debug
AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996
Figure 7-7. Test Formats: 4-Kbyte TLB
EDX: Array Pointer
031 30 29 28 27
0 0
Array ID
(E8h, E9h)
Way
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Set
EAX: Test Data
(E8h) 4-Kbyte Page and Status
(E9h) 4-Kbyte Linear Tag
0 0 0 0 0 0 0 0 0 0
Valid Bits
0
0 0 0 0 0 0 0 0 0 0 0 0
Valid Bits
871213
31
02131 22
1920

AMD K5 Specifications

General

Manufacturer	AMD
Model	K5
Architecture	x86
Microarchitecture	K5
Introduction Year	1996
Clock Speed	75 - 133 MHz
Core Count	1
Socket	Socket 7
Core stepping	SSA/5, 5k86
Voltage	3.3V
Transistors	4.3 million
L1 Cache	8 KB (data) + 16 KB (instruction)
FSB	50 MHz to 66 MHz
Process Technology	350 nm
