7-10 Test and Debug
AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996
7.4.3 Array Test Data
EAX specifies the test data to be read or written with the
RDMSR or WRMSR instruction (see Figures 7-3 through 7-8).
For example, in Figure 7-3 (top) the array pointer in EDX spec-
ifies a way and set within the data-cache linear tag array (E1h
in bits 7–0 of the array pointer) or the physical tag array (ECh
in bits 7–0 of the array pointer). If the linear tag array (E1h)
were accessed, the data read or written includes the tag and
the status bits. The details of the valid fields in EAX are shown
in Appendix A of the AMD-K5 Processor Software Development
Guide, order# 20007.
Figure 7-3. Test Formats: Data-Cache Tags
EDX: Array Pointer
031 30 29 28 27
0 0
Array ID
(E1h, ECh)
Way
0 0 0 0 0 0 0 0
Set
0 0 0 0 0
EAX: Test Data
(E1h) Linear Tag
(ECh) Physical Tag
0
0 0 0 0
Valid Bits
0
0 0 0 0 0 0 0 0 0
Valid Bits
8712131819
31 28 27
31 23 22
