AMD K5 User Manual

2-2 Internal Architecture
AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996
Figure 2-1. Internal Architecture, with Pipeline Stage
1
5
2 3
4
Fetch
Decode
Load
Store
Execute
8 Ports
64
Result
Retire
Fastpath Hardware ROPs
M Code Microcode ROPs
R.S. Reservation Station
Port 41 bits
Address
Data
32
8 Ports
4 Ports
5 Ports
2 Ports
Load
Store
Prefetch & Predecode
Branch Prediction
Instruction
Cache
Linear Tags
Byte
Queue
Fast
Path
M
Code
Fast
Path
M
Code
Fast
Path
M
Code
Fast
Path
M
Code
R.S.
R.S.
ALU
R.S.
ALU
R.S.
Branch
R.S.
FPU
Load
Store
Load
Store
Reorder Buffer
(ROB)
Register File
(x86 GPRs, FPRs)
Memory Management Unit
(TLBs and Physical Tags)
Bus Interface Unit
Data
Cache
Linear Tags
Store
Buffer
4 Ports

AMD K5 Specifications

General

Manufacturer	AMD
Model	K5
Architecture	x86
Microarchitecture	K5
Introduction Year	1996
Clock Speed	75 - 133 MHz
Core Count	1
Socket	Socket 7
Core stepping	SSA/5, 5k86
Voltage	3.3V
Transistors	4.3 million
L1 Cache	8 KB (data) + 16 KB (instruction)
FSB	50 MHz to 66 MHz
Process Technology	350 nm
