6-26 System Design

AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996

Table 6-2. SMM State-Save Area Map

Offset (hex) Contents Size (bits) Type

FFFC CR0 32 read-only

FFF8 CR3 32 read-only

FFF4 EFLAGS 32 read/write

FFF0 EIP 32 read/write

FFEC EDI 32 read/write

FFE8 ESI 32 read/write

FFE4 EBP 32 read/write

FFE0 ESP 32 read/write

FFDC EBX 32 read/write

FFD8 EDX 32 read/write

FFD4 ECX 32 read/write

FFD0 EAX 32 read/write

FFCC DR6 (FFFF_CFF3h) 32 read-only

FFC8 DR7 32 read-only

FFC4 TR 16 (upper 16 reserved) read-only

FFC0 LDTR 16 (upper 16 reserved) read-only

FFBC GS 16 (upper 16 reserved) read-only

FFB8 FS 16 (upper 16 reserved) read-only

FFB4 DS 16 (upper 16 reserved) read-only

FFB0 SS 16 (upper 16 reserved) read-only

FFAC CS 16 (upper 16 reserved) read-only

FFA8 ES 16 (upper 16 reserved) read-only

FFA4 I/O Trap Dword 32 (See Section 6.3.6) read-only

FFA0 reserved 32 —

FF9C I/O Trap EIP 32 read-only

FF98 reserved 32 —

FF94 reserved 32 —

FF90 IDT Base 32 read-only

FF8C IDT Limit 16 (upper 16 reserved) read-only

FF88 GDT Base 32 read-only

FF84 GDT Limit 16 (upper 16 reserved) read-only

Notes:

1. Locations marked “reserved” may change in future processors.

2. Writing locations marked as “read-only” has unpredictable results.
