2-20 Internal Architecture

AMD-K5 Processor Technical Reference Manual 18524C/0—Nov1996

Table 2-3. Cache States for Snoops, Invalidation, and Replacements

Type of

Operation

Tags

Cache State

Before

Operation

Memory Access

Cache State After Operation

MESI State

Writeback-

Writethrough State

Inquire

Cycle

Physical

shared or exclu-

sive

—

INV=0 shared writethrough

INV=1 invalid invalid

modified

burst write (write-

back)

INV=0 shared writethrough

INV=1 invalid invalid

Internal

Snoop

Physical

shared or exclu-

sive

—

invalid invalid

modified

burst write (write-

back)

FLUSH

Signal

Physical

shared or exclu-

sive

—

invalid invalid

modified

burst write (write-

back)

WBINVD

Instruction

Physical

shared or exclu-

sive

—

invalid invalid

modified

burst write (write-

back)

INVD

Instruction

— — — invalid invalid

Cache-Line

Replacement

Physical

shared or exclu-

sive

—

Depends on

replacement-line

characteristics

modified

burst write (write-

back)

Notes:

1. Linear tags are masked by A20M, physical tags are not.

2. Writeback = 32 bytes.

3. MESI state is stored in the physical tags. Instruction-cache state consists only of valid (shared) or invalid, and there are no write-

related states.

— Not applicable or none.
