FOR-A HVS-490 - Masking Chromakeys; Resetting Chromakey Channels

102
 Adjusting chromakey edges
<MATTE (KEY) >
[EFFECT/MELite > CK1 > MATTE > FILTER] menu
Parameter
Description
MATTE FILTER H
Applies H/V filter in the LOW, HIGH or MID levels.
MATTE FILTER V
MATTE RECURSIVE FILTER
Applies recursive temporal filter.
[EFFECT/MELite > CK1 > MATTE > EDGE SHRINK] menu
Parameter
Description
MATTE EDGE SHRINK TOP
Reduces the upper or lower MATTE edge by 1 line.
MATTE EDGE SHRINK BOTTM
MATTE EDGE SHRINK LEFT
Reduces the right or left MATTE edge by a half pixel.
MATTE EDGE SHRINK RIGHT
<FG (foreground)>
[EFFECT/MELite > CK1 > FOREGROUND > REPLACE] menu
Parameter
Description
FG EDGE REPLACE TOP
Replaces foreground side edges with internal colors.
FG EDGE REPLACE BOTTOM
FG EDGE REPLACE LEFT
FG EDGE REPLACE RIGHT
[EFFECT/MELite > CK1 FOREGROUND > FILTER] menu
Parameter
Description
FG RECURSIVE FILTER
Applies recursive temporal filter.
12-4-3. Masking Chromakeys
A box mask (unkeyed area) can be applied to chromakeys in the [EFFECT/MELite > CK1 >
MASK] menu.
PAGE 13
Parameter
Description
BOX MASK
Toggles BOX MASK ON /OFF.
INVERT
Toggles BOX MASK inversion ON /OFF.
GAIN
Adjusts the BOX MASK gain.
EDGE SOFT
Applies the BOX MASK edge softness in pixels.
PAGE 14
BOX MASK TOP
Specifies the BOX MASK top, bottom, left and right positions.
BOX MASK BOTTOM
BOX MASK LEFT
BOX MASK RIGHT
12-4-4. Resetting Chromakey Channels
(1) Open the [EFFECT/MELite > CK1 > INIT] menu.
(2) To preserve the signal selection, turn F2 to turn XPT HOLD to ON.
(3) Turn F1 to select EXEC and press F1. Tap YES in the confirmation dialog.
