Appendix 2 GPI/GPO/TALLY Function Lists
 GPI IN Functions
FUNCTION setting
TARGET setting
Triggers
NONE
NONE
No function is assigned.
AUTO TRANS
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
FLEXaKEY1-4
AUX1-12
M/E1-2 NEXT
AUX1-12 NEXT
Performs AUTO transitions.
CUT TRANS
Performs CUT transitions.
CUT/AUTO TRANS
Holding down AUTO performs AUTO transitions.
Pressing AUTO performs CUT transitions.
KEY ON
M/E1 KEY1-4
M/E2 KEY1-4
FLEXaKEY1-4
KEY ON
KEY OFF
KEY OFF
TRANS TYPE MIX
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
FLEXaKEY1-4
AUX1-12
M/E1-2 NEXT
AUX1-12 NEXT
Changes transition type to MIX.
TRANS TYPE WIPE
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
AUX1-12
Changes transition type to WIPE.
TRANS TYPE FAM
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
Changes transition type to FAM.
TRANS TYPE NAM
Changes transition type to NAM.
TRANS TYPE PRESET
BLACK
M/E2 BKGD
Changes transition type to PRESET BLACK.
BLACK TRANS
M/E2
Performs BLACK transitions.
AUX TRANS ENABLE
AUX01-12
Enables AUX transitions.
AUX TRANS DISABLE
Disables AUX transitions.
AUX TRANS CUT
AUX01-12
Sets AUX transition type to CUT.
AUX TRANS MIX
Sets AUX transition type to MIX.
AUX TRANS WIPE
Sets AUX transition type to WIPE.
FLX1 ASSIGN
M/E1，2
AUX01-12
Changes FLEXaKEY1 output target.
FLX2 ASSIGN
Changes FLEXaKEY2 output target.
FLX3 ASSIGN
Changes FLEXaKEY3 output target.
FLX4 ASSIGN
Changes FLEXaKEY4 output target.
MELite1 ASSIGN
AUX01-06
Changes MELite assignments.
MELite2 ASSIGN
MELite3 ASSIGN
AUX07-12
MELite4 ASSIGN
EDITOR ENABLE
ON, OFF
Enables/disables editor control.
USER FLAG ON
1-60
Turns USER FLAG to ON.
USER FLAG OFF
Turns USER FLAG to OFF.
USER FLAG TOGGLE
Turn USER FLAG ON/OFF.
MACRO PLAY (CH1-4)
0-99
Executes macros. (CH4 is dedicated for remote
control.)
EVENT RECALL
0-99
Recalls events.
