FOR-A HVS-490 User Manual

121
16-3. Clip Adjustment
Signal level thresholds for all color correction outputs (Clip adjustment) can be adjusted in Y/C
(YBR) or RGB mode. If Clip adjustment is disabled (ENABLE to OFF), default values are applied to
output signals.
<To Set Clip in Y/C Mode>
(1) Open [SETUP > COLOR CORRECT > CC1] menu PAGE 5.
(2) Turn F4 to select YBR.
SETUP > COLOR CORRECT > BUS CC M/E1 CH1
5/7
Y/C CLIP
Y/C CLIP
Y/C CLIP
CLIP ENABLE
YW
YB
C
100%
-7%
111%
YBR
(3) Turn F1 to F3 to set each parameter limit respectively.
SETUP > COLOR CORRECT > CC1
5/7
Y/C CLIP
Y/C CLIP
Y/C CLIP
CLIP ENABLE
YW
YB
C
109%
-7%
111%
YBR
Parameter
Description
Default
Setting
YW
Sets the WHITE limit in Y signal.
109%
50% to 109%
YB
Sets the BLACK limit in Y signal.
-7%
-7% to 50%
C
Sets the WHITE limit in C signal.
111%
50% to 111%
<To Set Clip in RGB Mode>
(1) Open [SETUP > COLOR CORRECT > CC1] menu PAGE 5.
(2) Turn F4 to select RGB.
(3) Turn F1 to F3 to set each R, G and B limit for WHITE in PAGE 5 and for BLACK in PAGE 6.
SETUP > COLOR CORRECT > CC1
5/7
RGB WHITE
RGB WHITE
RGB WHITE
CLIP ENABLE
CLIP R
CLIP G
CLIP B
300%
300%
300%
RGB
SETUP > COLOR CORRECT > CC1
6/7
RGB BLACK
RGB BLACK
RGB BLACK
CLIP R
CLIP G
CLIP B
300%
300%
300%
Parameter
Description
Default
Setting
WHITE
R / G / B
Sets the WHITE limit using R,
G and B.
300%
50% to 300%
BLACK
R / G / B
Sets the WHITE limit using R,
G and B.
-200%
-200% to 50 %
