136

19. Event Memory

The switcher can save settings as a data set. This function is called Event Memory. Event Memory

allows you to quickly recall saved panel settings at any time when needed. The MEMORY block is used

to save and recall events. In addition, data to be stored to or loaded from events can be selected in the

menu.

Event memory data can be backed up to SD cards. (See Sec. 22. “File Operations”)

In addition, the RATE item in the EVENT menu allows users to perform transitions by loading

events. (See Sec. 19-2-3. "Transitions Using Event Recall.")

19-1. Storing Events

Event memory can store control panel settings.

Up to 100 events (10 memory pages,

with 10 events per page) can be stored in memory.

 To Store Events (basic):

(1) Press EVENT in the MEMORY block.

(2) Press STORE on the numeric keypad.

(3) Press a number button (0-9) on the numeric

keypad to store the event.

Ex) To Save Settings to EVENT 03

Successively press EVENT > STORE > 3.

(Note that, in this case, the settings are saved to 3

of the current page (PAGE 0).)

 Storing Events (detailed):

(1) Press EVENT in the MEMORY block.

The [EVENT MEMORY] menu is displayed

and the keypad switches to EVENT mode.

(2) Press PAGE above the keypad.

(3) Select a page by pressing a number button.

PAGE 0 has EVENT0-9.

PAGE 1 has EVENT10-19…and the last page,

PAGE 9 has EVENT90-99.

(4) Press STORE.

The button will flashes green and the [EVENT

STORE] menu will appear.

This menu allows you to fine-select the data

to be saved. (See the next page.)

(5) Press a numeric key on the keypad to save

the settings to the event number.

CONTROL

MEMORY

M/E1

M/E2

MENU LOCK KEY PRI PAGE

DIRECT PATT MACRO EVENT SEQUENCE

INC

DEC

7 8 9

4 5 6

1 2 3

RECALL STORE

ENTER

CLEAR

+ / -

CK WIPE SUB EFF

FLX4FLX3FLX2FLX1

KEY1 KEY2 KEY3 KEY4
