FOR-A HVS-490 - Tally Output

176
25-2. Tally Output
Tally information can be output from the GPI /TALLY OUT connectors. Tallies can be assigned to
the GPI/TALLY OUT connector on the HVS-490. (See Sec. 25-2-2. "Tally Output Settings (GPI
/TALLY OUT)." for details on settings.)
Tally information can also be output via the GPI I/O connector on the control panel.
25-2-1. Tally Color Settings
(1) Open the [SETUP > GPI TALLY > TALLY COLOR] menu.
(2) Turn F1 to select a bus (M/E1 PGM in the below example).
(3) Turn ON the color to be used for the bus: RED, GREEN, or COLOR1-24.
Set colors for M/E1 PST, M/E2 PGM, M/E2 PST, AUX buses and EXT TALLY in the same
manner.
SETUP > GPI TALLY > TALLY COLOR
1/9
SELECT
RED
GREEN
M/E1 PGM
OFF
OFF
SETUP > GPI TALLY > TALLY COLOR
2/9
SELECT
COLOR01
COLOR02
COLOR03
M/E1 PGM
OFF
OFF
OFF
SETUP > GPI TALLY > TALLY COLOR
9/9
SELECT
COLOR22
COLOR23
COLOR24
M/E1 PGM
OFF
OFF
OFF
Tally Color settings made in this menu are shared with those for the GPI I/O connector.
 Tally Color Memory
Up to 30 sets of tally color settings can be saved to Tally Color Memory.
SETUP > GPI TALLY > TALLY COLOR MEMORY
1/1
STORE
RECALL
NO.01
NO.01
Saving Tally Color Settings
(1) Open the [SETUP > GPI TALLY > TALLY COLOR MEMORY] menu.
(2) Turn F1 to select a memory number.
(3) Press F1. A confirmation dialog will appear. Tap YES to save the current tally color
settings to the memory number. Once data is saved, an asterisk "*" is added after the
number such as "No.01*".
Loading Tally Color Settings
(1) Open the [SETUP > GPI TALLY > TALLY COLOR MEMORY] menu.
(2) Turn F2 to select a memory number.
(3) Press F2. A confirmation dialog will appear. Tap YES to load the tally color settings to the
switcher.
