22-4-3. Loading Image Files
JPEG. TARGA or BITMAP image files can be loaded to STILL1-4 and INPUT STILL buffers
using SD cards. The following procedure explains how to download a JPEG file to STILL1 as
an example.
(1) Insert the SD card in which the JPG file is stored, into the card slot.
(2) Open the [FILE > LOAD] menu.
(3) Turn F1 to select SD/ (the folder in which the file is stored) and press F1.
(4) Turn F2 to select STILL, and press F2.
(5) Turn F3 to select STILL1.
(6) Tap a JPEG file in the menu screen.
(7) Tap YES on the pop-up screen to load the file to STILL1.
FILE > LOAD
1/1
SELECT
TYPE
TARGET
EXEC
STILL
STILL1
Image File Upload Targets
Upload Target
Description
STILL1-STILL4
Loads to each still buffer.
Once an image is uploaded, the previous image is replaced with this.
IN01-IN40
(INPUT STILL)
Loads to each input frame buffer.
Once an image is uploaded, the input bus automatically displays the image
instead of input video.
To recover the input video display, change CONTROL to INPUT in the [SETUP >
INPUT > SIGNAL] menu. (See Sec. 17-3-2. Returning to Input Video Display.”)
V-RAM
Stores into the built-in video memory.
TIPS
Tapping STILL THUMB in the right side of the menu screen allows you to display in
thumbnail mode.
Tapping UPDATE IMAGES allows you to create thumbnails for still images in the page,
(This will take several minutes.) and save cache files (.490cache) in the SD cards.
22-4-4. Loading Sequential Image Files
JPEG. TARGA or BITMAP sequential image files can be uploaded to the switcher and used as
clips as shown below.
(1) Insert the SD card in which sequential image files (with up to 16 file names) are stored,
into the card slot.
(2) Open the [FILE > DATA BACKUP] menu. Turn F2 to select CLIP, then press F2.
(3) Turn F1 or tap on the menu screen to specify the folder that contains the image files.
(4) Turn F4 to select CREATE CLIP, then press F4.
FILE > DATA BACKUP
1/1
SELECT
TYPE
MODE
EXEC
FOLDER
CLIP
SOURCE
CREATE
CLIP
(5) Open the [FILE > LOAD] menu and turn F2 to select CLIP, then press F2.
(6) Turn F4 to select a load destination.
(7) Turn F1 to specify the folder specified in Step (3) and press F4. (Or, tap the folder on the
menu screen.)
