26-2. 4K Mode Specifications (HVS-49EXP4K Option)
4K UHD
(3840 x 2160)
59.94 / 50p
Quad Link 3G-SDI Level-A/B-DL (2SI/SQD) 4:2:2 YCbCr 10-bit
* Level-B-DL input signals are output as Level-A signals.
29.97 / 25 / 24 / 23.98p
Dual Link 3G-Level-B-DS (2SI) 4:2:2 YCbCr 10-bit
Quad Link 1.5G-SDI (SQD) 4:2:2 YCbCr 10-bit
29.97 / 25 / 24 / 23.98 PsF
59.94 / 50i
Quad Link 1.5G-SDI (SQD) 4:2:2 YCbCr 10-bit
SDI input
8 inputs (Max 10 inputs) * Frame synchronizer on each input
SDI output
4 outputs (Max 5 outputs)
HDMI output
2 outputs HDMI2.0 Level-B (YUV 4:2:0)
WIPE pattern
Available (limited patterns)
(See "Appendix 4 Transition Patterns.")
WIPE modify
Same manner as working in normal (HD) mode
(Only borders available in SQD mode)
Transition
Execution: Fader lever, AUTO or CUT button
Type: MIX and WIPE
DVE
Available in 2SI mode
4 channels (2 channels for 1080/59.94p and 50p signals)
* With HVS-49DVE card installed:
5 channels (4 channels for 1080/59.94p and 50p signals)
KEYER
2 channels (KEY1 and KEY2)
Luminance, Full, and Bus keying and Box mask
Pattern mask and EDGE (Available in 2SI mode)
FLEXaKEY
One channel
Luminance, Full, and Bus key
Displayed on M/E or AUX
Chromakey
1 channel (59.94p, 50p unsupported)
Sub Effects
1 channel (59.94p, 50p unsupported)
Mosaic and Defocus available only in 2SI mode.
Color Corrector
1 channel
Multiviewer
3 channels (2K output)
Layout patterns limited
* See “Multiviewer function in 4K mode.”
UTILITY
1 channel
STILL
1 channel
INPUT STILL available for all inputs
Event memory
100 events: Crossfade switching available during event recall
* Event data in Normal mode are unavailable.
Macro
Same as in normal mode
Genlock Input
System Phase Adjust
Genlock Output
I/O Delay
Unavailable functions
Side panel
MELite re-entry into M/E, KEYER or M/E FLEXaKEY is disabled in
SQD mode.
Parameters to be reset
by switching to 4K mode
M/E 1, M/E 2, AUX and MELite settings
KEY LINK and FLEXaKEY settings
Side Panel, MV and Standard Color Corrector settings
