155
To Delete a Macro Page
(1) Press MACRO in the MEMORY block to display the MACRO menu.
Go to PAGE 3.
(2) Turn F2 to select a page, then press F2.
To Delete All Macro Data
Turn F2 to select ON under PAGE CLEAR, then press F3.
21-3-4. Copying, Moving and Exchanging Macro Data
To Copy Macro Data
(1) Press MACRO in the MEMORY block to display the MACRO menu.
(2) Go to PAGE 4.
(3) Turn F1 to select a macro number to be copied.
(4) Turn F2 to select a target macro number.
(5) Turn F3 to select COPY, then press F3.
No. 00 macro is copied to No. 01 in the example below.
To Move Macro Data
Selecting MOVE instead of COPY, the macro data is moved.
To Exchange Macro Data
Selecting SWAP instead of COPY, the macros are exchanged.
Copying, moving or exchanging macros between No.90-99 and No.00-89, only the first 30
actions are used.
21-3-5. Macro Play Channel
Three play channels are provided to macros and able to execute macros simultaneously on
different controllers. For example, the HVS-492OU (keypad) plays a macro using CH1 while
the Web GUI plays another macro using CH2. The macro execution channel can be changed
in the menu.
(1) Open MACRO menu PAGE 5.
(2) Turn F4 to change the execution channel used on the keypad.
Select channels for macro execution buttons in the [PANEL > MACRO ATTACH > MACRO
CH] menu.
