FOR-A HVS-490 User Manual

32
4-1-2. HVS-490 (MU)
Open the [SETUP > SYSTEM > NETWORK] menu and configure LAN (HVS) settings in
PAGE 1 and LAN (EXT) settings in PAGE 2.
SETUP > SYSTEM > NETWORK
1/2
LAN1(HVS)
LAN1(HVS)
LAN1(HVS)
LAN1(HVS)
IP ADDRESS
NETMASK
GATEWAY
MAC ADDRESS
192.168.0.10
255.255.255.0
192.168.0.1
XXXXXXXXXXXX
SETUP > SYSTEM > NETWORK
2/2
LAN2(EXT)
LAN2(EXT)
LAN2(EXT)
LAN2(EXT)
IP ADDRESS
NETMASK
GATEWAY
MAC ADDRESS
192.168.1.10
255.255.255.0
192.168.0.1
XXXXXXXXXXXX
To change IP ADDRESS or GATEWAY, press F1 to F3 to enter a new address, then press
Enter.
To change NETMASK, turn F2 to change the number and press F2.
4-1-3. Control Panel
Open the [PANEL > NETWORK > NETWORK] menu and set the control panel LAN (HVS)
address under IP ADDRESS and specify the HVS-490 to be controlled using LAN1 address
under CONTROL MU IP ADDRESS. To configure multiple operation units to the switcher,
each unit must have a unique IP address and OU ID. Up to 3 controllers can be configured.
The Mac Address of the control panel (OU) LAN port is displayed in PAGE 2.
PANEL > NETWORK > NETWORK
1/2
IP ADDRESS
NETMASK
CTRL MU
OU ID
IP ADDRESS
192.168.0.12
255.255.255.0
192.168.0.10
1
To change IP ADDRESS, press F1 to F3 to enter a new address, then press Enter.
To change NETMASK or OU ID, use F2 or F4 to change values then press F2 or F4.
Set OU HVS LAN IP address.
MU LAN (HVS) IP address
