19-5. User Default Setting
The event store data can be changed from the factory default settings (M/E1 and M/E2).
(1) Press EVENT in the MEMORY block to display the [EVENT MEMORY] menu.
(2) Press STORE in the keypad.
(3) Select data to be stored in the menu screen.
(4) Go to [EVENT MEMORY] menu PAGE 2.
(5) Turn F4 to change PREFERENCE to EXEC and press F4.
(6) Select YES in the pop-up dialog to save the current settings as default store data.
19-6. Loading an Event at Start-up
The settings made for the background and key buses on the control panel are cleared when
powering off the switcher. You can, however, recall the desired panel setup whenever the switcher
starts by setting in the [SETUP - SYSTEM - INIT] menu as shown in the procedure below.
(1) Open the [SETUP > SYSTEM > INIT] menu.
(2) Turn F2 to select the desired panel setup in the table below.
The switcher starts with Last Saved Settings.
"Last Saved Settings" are automatically saved when the unit is
rebooted or SETUP is pressed.
The switcher starts with the last loaded event.
Note that to enable the Last Load function, an event must be
loaded after setting to LAST.
The switcher starts with a selected event (0-99) loaded.
To Next Page
