FOR-A HVS-490 - TSL UMD Protocol

187
25-4. TSL UMD Protocol
The switcher supports the TSL UMD 5.0 protocol, through which tally export and signal name
import/export over Ethernet are available. FOR-A multi-viewer units can receive tally information
sent from HVS-490 units. The HVS-490 can receive signal names from FOR-A MFR Series routers.
Use the LAN EXT port on the HVS-490 units for sending / receiving TSL messages.
 Receiving Signal Names (TSL IN)
The HVS-490 can receive source signal names using TSL UMD 5.0 by setting in the [SETUP >
TSL > TSL IN] menu.
SETUP > TSL > TSL IN
1/2
TSL IN
LAN2(EXT)
LAN2(EXT)
SCREEN NO
IP ADDRESS
PORT
DISABLE
192.168.1.10
8901
0
SETUP > TSL > TSL IN
2/2
DISPLAY ID
NAME LINK
DLE OPTION
OFFSET
0
OFF
OFF
Parameter
Description
TSL IN
Setting to ENABLE starts receiving TSL commands.
LAN2(EXT) IP ADDRESS
Displays MU LAN2 (EXT) IP address.
LAN2(EXT) PORT
Displays MU LAN2(EXT) port number
SCREEN NO
Sets a TSL screen number.
DISPLAY ID OFFSET
Sets the Display ID start position. (See the table below.)
NAME TYPE
Turing ON applies received signal names to the switcher signal names.
DLE OPTION
Turns Data Link Escape on/off.
Display ID numbers are defined as shown below.
To change Display ID numbers, specify the start position under DISPLAY ID OFFSET.
Signal
name
INPUT
01-40
AUX
01-12
M/E1
PGM
M/E1
PVW
M/E1
CLN1
M/E1
CLN2
M/E2
PGM
M/E2
PVW
M/E2
CLN1
M/E2
CLN2
AUXPST
01-12
ID
0-39
50-61
70
71
72
73
80
81
82
83
100-111
 Sending Tally Information and Signal Names (TSL OUT)
To send signal names and RED/GREEN tallies through TSL UMD 5.0, set in the [SETUP >
TSL > TSL OUT] menu. As factory default, the port is set up as shown below.
SETUP > TSL > TSL OUT
1/2
TSL OUT
DLE OPTION
SCREEN NO
DISPLAY ID
OFFSET
DISABLE
OFF
0
0
SETUP > TSL > TSL OUT
2/2
TARGET
TARGET
IP ADDRESS
PORT
192.168.0.13
8901
Parameter
Description
TSL OUT
Setting to ENABLE starts sending TSL commands, in which input source
names, and AUX and M/E OUT output tally information are included for
FOR-A switchers (input source names, and Mode 1 tally information for
FOR-A multi-viewers)
DLE OPTION
Turns Data Link Escape on/off.
SCREEN NO
Sets the TSL screen number.
DISPLAY ID OFFSET
Sets the Display ID start position.
TARGET IP ADDRESS
Specify the target IP address.
TARGET PORT
Specify the target port number.
