15. SUB EFFECT
Sub effects such as Mono Color, Defocus, Paint and Mosaic can be added to video images. Up to 4 Sub
Effect channels are available in HD/SD mode. Sub Effect channels can be output from AUX buses by
assigning as SUBEFF1-4, and used for video sources such as Key Source/Insert and Background
images. Up to 3 Sub Effect channels are available in 1080/59.94p, 50p mode.
► See Sec. 6-2. “Mapping Video Sources to Bus Buttons.”
► See Sec. 8-2-2. “Selecting a Video Using the Menu.”
15-1. Assigning a SUB EFFECT Channel to a Bus
(1) To use the SUB EFF1 channel, open the [EFFECT/MELite > SUBEFF1 > SIGNAL] menu.
(2) Turn F1 to select a signal to be applied to.
EFFECT/MELite > SUBEFF1 > SIGNAL
1/5
SIGNAL
IN01
15-2. Applying Sub Effects
 MONO COLOR
Monochrome effects can be configured via the following menu page.
Turn MONO ENABLE to ON and set a color using SAT and HUE.
EFFECT/MELite > SUBEFF1 > MONO
2/5
MONO SAT
MONO HUE
MONO ENABLE
50
50
ON
 DEFOCUS
Defocus allows you to add an effect that will blur the image.
Set the horizontal defocus level under DEFOCUS H.
Set the vertical defocus level under DEFOCUS V.
EFFECT/MELite > SUBEFF1 > DEFOCUS
3/5
DEFOCUS H
DEFOCUS V
PAINT Y
PAINT C
40.0
50.0
0
0
 PAINT COLOR
(*1)
The Paint Color effect allows you to add an effect, which makes the image look like a painting.
Increasing the value decreases the degree of gradation, so the image resembles a painting.
Set the luminance level under PAINT Y and chrominance level under PAINT C.
EFFECT/MELite > SUBEFF1 > DEFOCUS
3/5
DEFOCUS H
DEFOCUS V
PAINT Y
PAINT C
0
0
0
0
 FREEZE, STROBE
(*1)
, NEGA and MOSAIC
Freeze, Strobe, Nega and Mosaic effects are also available by turning each parameter ON under
the setting.
EFFECT/MELite > SUBEFF1 > FREEZE
4/5
FREEZE
STROBE
NEGA
MOSAIC
OFF
OFF
OFF
OFF
