158
22. File Operations
The switcher is capable of storing operational data, such as system and bus setting data, still images,
WIPE and DVE modifications and event data, to SD cards and of recalling and downloading previously
saved data for application to production operations.
22-1. Notes on SD Cards
ï‚Ÿ Gentrly insert/remove an SD card with its label facing upwards.
ï‚Ÿ Do NOT remove the SD card when it is storing or reading data. Otherwise, it cause
malfunction or data loss.
22-2. Setting and Image Files
Supported Menu Setting Files and Image Files
ALL data including System data, all WIPE/DVE data and all event and macro
memory data
System data (SETUP and CURRENT menus and three control panel data)
Active control panel data
Still images in JPEG format
JPEG images (standard RGB)
Still images in TARGA format
8-, 24- and 32-bit TARGA images (uncompressed RGB and RLE encoded)
Still images in BITMAP format
24-bit BITMAP images (uncompressed RGB)
Note that file names are limited to max. 16 characters in length (ASCII code).
(*1) Files are automatically named to their correct name as shown in the table above when saving to SD
cards.
22-3. Saving Data (from Switcher to SD Card)
This section explains how to save all switcher settings to SD cards as an example.
(1) Insert an SD card into the card slot.
(2) Open the [FILE > SAVE] menu.
(3) Turn F1 or tap the folder icon to select SD/ (SD card to which the data is to be backed up).
(4) Turn F2 to select ALL.
(5) Press F4.
(6) Tap on YES on the confirmation dialog to save the data to the SD card.
To Next Page
