M/E1 PGM XPT
XPT
Changes M/E1 PGM signal selection.
M/E1 PST XPT
Changes M/E1 PST signal selection.
M/E2 PGM XPT
Changes M/E2 PGM signal selection.
M/E2 PST XPT
Changes M/E2 PST signal selection.
AUX01-20 XPT
Changes AUX01-20 signal selection.
AUX01-16 PST XPT
Changes AUX01-16 PST signal selection.
 GPI OUT Functions
FUNCTION setting
TARGET setting
Description
NONE
NONE
No function is assigned
TRANS PROC
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
FLEXaKEY1-4
AUX1-12
Outputs while TARGET transition is being
performed.
AUTO TRANS PROC
Outputs while TARGET AUTO transition is being
performed.
KEY ON
M/E1 KEY1-4
M/E2 KEY1-4
FLEXaKEY1-4
Outputs while the TARGET key is on-air.
TRANS TYPE MIX
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
FLEXaKEY1-4
AUX1-12
Outputs when the TARGET transition TYPE is set to
MIX.
TRANS TYPE WIPE
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
AUX1-12
Outputs when the TARGET transition TYPE is set to
WIPE.
TRANS TYPE FAM
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
Outputs when the TARGET transition TYPE is set to
FAM.
TRANS TYPE NAM
Outputs when the TARGET transition TYPE is set to
NAM.
TRANS TYPE PRESET
BLACK
M/E2 BKGD
Outputs when the TARGET transition TYPE is set to
PRESET BLACK.
ASPECT
16 : 9
4 : 3
Outputs when the TARGET aspect ratio is set.
FLX1 ASSIGN
M/E1,2
AUX1-12
Outputs when FLEXaKEY1 is assigned to TARGET.
FLX2 ASSIGN
Outputs when FLEXaKEY2 is assigned to TARGET.
FLX3 ASSIGN
Outputs when FLEXaKEY3 is assigned to TARGET.
FLX4 ASSIGN
Outputs when FLEXaKEY4 is assigned to TARGET.
ALARM
ALL
FAN
PS1,2
FPGA
Outputs when the TARGET alarm occurs.
USER FLAG
1-60
Outputs depending on the TARGET user flag state.
CUT TRANS PROC
M/E1 BKGD
M/E1 KEY1-4
M/E2 BKGD
M/E2 KEY1-4
FLEXaKEY1-4
AUX1-12
Outputs while the TARGET is in CUT transition.
FADER TRANS PROC
Outputs while the TARGET is in transition using a
fader.
