FOR-A HVS-490 User Manual

104
 UTILITY MASK
Video inputs can be used for mask signals instead of Box. Inputs used for masks must be
assigned to UTILITY1 or UTILITY2. Combined video signals such as program or multi-view
cannot be used.
(1) Create M/E1 KEY1.
(2) Quickly press KEY1 twice in BUS SELECT to display the [M/E FLEXaKEY > M/E1 >
KEY1 > TRANS > MASK] menu.
(3) Select UTILITY1 or UTILITY2 under MASK TYPE.
M/E FLEXaKEY > M/E1 > KEY1 > TRANS > MASK
5/14
MASK TYPE
BOX&UTL/PAT
MASK & KEY
BOX MASK
INVERT
UTILITY1
AND
OFF
TIPS
The UTILITY 1 and 2 images should be selected in each ME menu: [M/E FLEXaKEY > M/E1
> BKGD PGM > TRANS > UTILITY] or [M/E FLEXaKEY > M/E2 > BKGD PGM > TRANS >
UTILITY] menu. (See Sec. 6-6. “UTILITY1-2.")
 PATTERN MASK
WIPE patterns can be used for mask signals for keys.
(1) Create M/E1 KEY1.
(2) Quickly press KEY1 twice in BUS SELECT to display the [M/E FLEXaKEY > M/E1 >
KEY1 > TRANS > MASK] menu.
(3) Select PATTERN under MASK TYPE.
M/E FLEXaKEY > M/E1 > KEY1 > TRANS > MASK
5/14
MASK TYPE
BOX&UTL/PAT
MASK & KEY
BOX MASK
INVERT
PATTERN
AND
OFF
(4) Go to PAGE 7. Select a mask pattern and level.
M/E FLEXaKEY > M/E1 > KEY1 > TRANS > MASK
7/14
PATTERN
PAT MASK
UTL/PAT MASK
LEVEL
INVERT
51
0.0
OFF
(5) Modify the pattern in the following pages if necessary.
M/E FLEXaKEY > M/E1 > KEY1 > TRANS > MASK
8/14
PAT MASK
PAT MASK
PAT MASK
PAT MASK
POS X
POS Y
ANGLE
ASPECT
0
0
0.0
0.0
M/E FLEXaKEY > M/E1 > KEY1 > TRANS > MASK
9/14
PAT MASK
PAT MASK
PAT MASK
PAT MASK
MULTI X
MULTI Y
ANGLE SPIN
SOFTNESS
1
1
0
0.0
TIP
Mixed mask signals using BOX, UTILITY and PATTERN are also available and can be
selected under MASK TYPE in the [M/E FLEXaKEY > M/E1 > KEY1 > TRANS > MASK]
menu.
