PANEL > BUS ASSIGN > LEVEL1
1/2
BUTTON
SIGNAL
INHIBIT
COLOR PALETTE
BTN03
RX003
OFF
PALETTE00
(3) Open [SETUP > ROUTER > XPT LINK] menu PAGE 2.
Select M/E1 A BUS under BUS SELECT. Set the switcher input and the router
destination channel as shown below.
SETUP > ROUTER > XPT LINK
2/2
BUS SELECT
INPUT
RTR DST
M/E1
A BUS
IN01
4
* The router level set in the [SETUP > ROUTER > MANUAL CONTROL] menu is applied to
this procedure.
 Router Link Operation
Pressing Bus Button 1 on the switcher M/E1 A bus displays the SRC7 image on the M/E
output.
Pressing Bus Button 2 on the switcher M/E1 A bus displays the SRC8 image on the M/E
output.
Pressing Bus Button 3 on the switcher M/E1 A bus displays the SRC9 image on the M/E
output.
<Available Bus for Router Link (Selectable bus under BUS SEL)>
(M/E1, M/E2, AUX1-12) A BUS, (M/E1, M/E2, AUX1-12) B BUS,
KEY1-4INS, KEY1-4SRC, FLX1-4INS, FLX1-4SRC,
AUX13-20
 Router Crosspoints
The maximum number of available router crosspoints: 256
The maximum number of available router sources: 1024
The maximum number of available router destinations: 256
