FOR-A HVS-490 - Page 190

190
(3) Go to PAGE 2 and set Button 2 on UNIT 2 as shown below.
SETUP > AUX UNIT > UNIT2
2/4
BUTTON
SELECT
FUNCTION
TARGET
BTN02
ROUTER
SRC
SRC05
(4) Press Button 2 on the UNIT 2 AUX box. The DST (Destination) 3 is switched to SRC
(Source) on the connected router.
 FUNCTION and TARGET Settings
AUX Box buttons light as shown below to indicate the status.
When an action is assigned to a button: Dim-lit
When an action is being performed: Lit green
FUNCTION (action type) setting
TARGET (action) setting
Description
NONE
(NOT ASSIGN)
AUX SELECT
AUX01-20
AUX01-12 PST
M/E1 PGM
M/E1 PST
M/E1 ABUS
M/E1 BBUS
M/E1 KEY1-4 INSERT
M/E1 KEY1-4 SOURCE
M/E2 PGM
M/E2 PST
M/E2 ABUS
M/E2 BBUS
M/E2 KEY1-4 INSERT
M/E2 KEY1-4 SOURCE
FLX1-4 INSERT
FLX1-4 SOURCE
Selects a bus.
AUX XPT
BLACK
IN01-40
STILL1-4
STILL1-4 KEY
COLOR BAR
WHITE
MATTE1-2
GMAT
CK1-4 FILL
CK1-4 KEY
SUBEFF1-4
M/E1-2 PGM
M/E1-2 PVW
M/E1-2 CLN1
M/E1-2 CLN2
M/E1-2 KEY
MELite1-2 PGM
MELite1-2 PST
MV1-3
RX001-256
Selects a signal for the current AUX bus.
The bus should be selected by the AUX
SELECT action, otherwise currently
selected in the menu (AUX SELECT in
the [SETUP >AUX UNIT > UNIT1(2-12)]
menu PAGE 1)
AUX01-AUX20
AUX01 PST-AUX12 PST
BLACK
IN01-40
STILL1-4
STILL1-4 KEY
COLOR BAR
WHITE
MATTE1-2
GMAT
CK1-4 FILL
CK1-4 KEY
SUBEFF1-4
M/E1-2 PGM
M/E1-2 PVW
M/E1-2 CLN1
M/E1-2 CLN2
M/E1-2 KEY
MELite1-2 PGM
MELite1-2 PST
MV1-3
Selects a signal for the selected bus.
AUX TRANS
AUX1-12
Turns the AUX bus transition ON/OFF.
AUX CUT
AUX MIX
AUX WIPE
AUX1-12
Selects the AUX bus transition type.
EVENT RECALL
EVENT NO.0-99
Loads an event.
MACRO RECALL
MACRO NO.0-99
Recalls a macro.
