214
FILE - LOAD
[FILE > LOAD]
FILE - SAVE
[FILE > SAVE]
STATUS - VERSION
[STATUS > VERSION]
STATUS - ALARM
[STATUS > ALARM]
STATUS - OPTION
[STATUS > OPTION]
TRANS - TRANS
[TRANS]
TRANS - BLACK TRANS
[BLACK TRANS]
KEYER - SRC INS
[SRC INS]
KEYER - MASK
[MASK]
KEYER - EDGE
[EDGE]
KEYER - PRIORITY
[PRIORITY]
KEYER - INIT
[INIT]
FLEXaKEY ASSIGN
[M/E/FLEXaKEY > FLX1 > TRANS > ASSIGN]
WIPE MODIFY - BORDER
[MODIFY > WIPE BORDER]
WIPE MODIFY - POS/ANGLE
[MODIFY > WIPE POS/ANGLE]
WIPE MODIFY - INIT
[MODIFY > WIPE INIT]
DVE MODIFY - POS/SIZE
[MODIFY > DVE POS/SIZE]
DVE MODIFY - ROTATION
[MODIFY > DVE ROTATION]
DVE MODIFY - BORDER
[MODIFY > DVE BORDER]
DVE MODIFY - INIT
[MODIFY > DVE INIT]
CG WIPE MODIFY
[MODIFY > CG WIPE MODIFY]
AUX TRANS
[EFFECT/MELite > AUX1(2-12) > TRANS]
MELite
[SETUP > OUTPUT > MELite]
SUB EFFECT1
[EFFECT/MELite > SUB EFFECT1]
SUB EFFECT2
[EFFECT/MELite > SUB EFFECT2]
SUB EFFECT3
[EFFECT/MELite > SUB EFFECT3]
SUB EFFECT4
[EFFECT/MELite > SUB EFFECT4]
CHROMA KEY1
[EFFECT/MELite > CHROMA KEY1]
CHROMA KEY2
[EFFECT/MELite > CHROMA KEY2]
CHROMA KEY3
[EFFECT/MELite > CHROMA KEY3]
CHROMA KEY4
[EFFECT/MELite > CHROMA KEY4]
MATTE
[EFFECT/MELite > MATTE1]
GRADIENT MATTE
[SETUP > MATTE > GRADIENT MATTE COLOR1]
COPY SWAP - COPY
[COPY SWAP]
COPY SWAP - SWAP
[COPY SWAP]
STILL - STILL CLIP
[STILL/CLIP > STILL CLIP]
STILL - INPUT
[STILL/CLIP > INPUT STILL]
SEQUENCE - FILE
[SEQUENCE > FILE]
SEQUENCE - EDIT
[SEQUENCE > EDIT]
 Assignable functions
When AUX is selected for TYPE:
Setting
Function
Button Indication
AUX1-20 MARKER ENABLE
Displays safety area markers.
ON: Lit orange,
OFF: Half-lit
AUX1-12 TRANS ENABLE
Enables AUX bus transitions.
When GPIO is selected for TYPE:
Setting
Function
Button Indication
USER FLAG1-60(PUSH)
Represents the ON/OFF setting for each USER FLAG1-60
assigned to a connector pin. The function is enabled
whenever the relevant USER button is pressed.
Lit when pushed,
unless Half-lit.
USER FLAG1-60(TOGGLE)
Represents the ON/OFF setting for each USER FLAG1-60
assigned to a connector pin. The function is enabled or
disabled each time the relevant USER button is pressed.
ON: Lit orange,
OFF: Half-lit
