Other Option Units
HVS-AUX16A/16B/32A/64A (*1)
Auxiliary Unit (Ethernet LAN connection)
Tally Control Unit (Relay type)
(Hanabi Series Option) (RS-422 connection)
Tally Control Unit (Open Collector type)
(Hanabi Series Option) (RS-422 connection)
(*1) Up to 12 units can be connected to the switcher LAN.
(*2) Multiple HVS-TALOC / HVS-TALR configurations possible; up to 5 units max.
Optional devices or software are basically provided with the installation manuals (except factory- installed
ones) or specific operation manuals.
About This Manual
This manual is intended to help the user easily operate this product and make full use of its
functions during operation. Before connecting or operating your unit, read this operation manual
thoroughly to ensure you understand the product. Afterwards, it is important to keep this manual in
a safe place and available for reference.
Font Conventions
The following conventions are used throughout this manual:
Text enclosed by a square (such as KEY1) indicates control panel buttons.
Bold text (such as SETUP) indicates menu tabs and buttons in the menu screen.
Shaded text (such as ON) indicates a parameter setting.
Text enclosed by square brackets (such as [SETUP > SYSTEM > FORMAT]) indicates the
menu name
