05/2014
3-36
DC SC2020
3.2.2 How to use the image quality troubleshooting (IPS)
Version 1.1
Image Quality Troubleshooting
27 Multi Color Transfer Failure Transfer If continuous print is performed in high humidity environ-
ment, the resistance of secondary transfer part rises
temporary. The necessary electric field cannot be
acquired from the drop of transfer electrical current,
which may result in lighter shade in multicolor.
High humidity
environment
Secondary transfer voltage off-set adjustment:
Optimize secondary transfer voltage with Mainte-
nance -> Adjust 2nd BTR (Set to Plus side).
28 Caterpillar Mark Transfer Caterpillar mark may appear with plain paper (thin
paper).
ALL Side-1
Side-2
Plain
(Lightweight
Paper)
Secondary transfer voltage off-set adjustment:
Optimize secondary transfer voltage with Mainte-
nance -> Adjust 2nd BTR (Set to Plus side).
29 Transfer wrinkle PH
Transfer
Transfer wrinkle may occur depending on the hydrated
status of the paper.
High humidity
environment
Side-1
Side-2
Hydrated
paper is a
stress.
Change to fresh paper and run.
30 Rear end shimmer (postcard) Transfer When printing transferred postcard, the postcard rear
edge gets flipped-up after going through the Reg Shoot
and moves closer to the center transfer belt which may
result in blurring of line or letter image near the rear edge
of the postcard (Toner gets scattered).
Low humidity
environment
Side-1 Postcard • Down curl the rear edge of the postcard.
• Reg Shoot Extension Miler KIT
31 Shimmer style Transfer Branch-like electric discharge print may appear on the K
color half-tone image part and line/solid part when
Duplex Print is performed.
Mid humid-
ity~HighHu-
midity
environment
Side-2 Plain
(Lightweight
Paper)
• Raise with secondary transfer voltage adjust-
ment.
• Raise the primary transfer electricity.
• Lower the TC (Toner density) in the develop-
ing machine.
• Replace the 2nd BTR Unit.
32 Starvation Devel-
opment
• White may generate on the border of solid part and
half tone part but may worsen when TC is high
(Low humidity environment).
• TC may overshoot on the tall side and worsen
immediately after replacing the Toner Cartridge.
Low humidity
environment
All All High TC • Performance limit
• Flip vertically and output.
• Output with A4SEF -> A4LEF.
33 Light-induced fatigue Xero If left alone without shading the photo receptor, the den-
sity may change from the photo receptor cycle. -> This
will disappear if left alone.
All Side-1
Side-2
All Immediately
after Xero
ERU replace-
ment
• Leave alone for overnight or replace Xero ERU
• Photo receptor replacement
34 BCR pitch density unevenness Xero BCR pitch density unevenness may occur depending on
the shape of BCR.
Low temper-
ature/Low
humidity
environment
Side-1
Side-2
All Detect with
HT image
Xero ERU Replacement
35 Galling Ghost Xero When continuous image is continuously printed in the
process direction like the Xero longitudinal rule line, the
image gets seared into the photo receptor and the
seared image gets detected when HT image is
extracted. -> This will disappear if left alone.
All Side-1
Side-2
All Continuous
print of same
• Leave alone for 30 minutes or replace Xero
ERU
• Photo receptor replacement
Table 1
Image Quality Problem Name SUB Details
Occurrence Condition
Interim Measures Details
Environmen
t
Side-1
Side-2 Media
Others
Conditions
To Next Page
