Fuji Xerox DocuCentre SC2020 Service Manual

7.3 BSD
Chain25 ESS
ABCDEFGHJ
1
2
3
4
5
6
7-57
j0bs732501
NOTE:
1
For the details of Controller Codes, see Chap. 2 FIPs.
25.1 ESS
ESS PWB
PL18.2
LVPS
ETHERNET
(10/100BASE-T)
P5
+3VDC
P432
FAX DATA
UI CONTROL
PANEL
SEE CH2
P436
DRIVE POWER
SEE CH1
P3
IOT
SEE CH3
P6
EEPROM
SEE CH1
J1
SPI FLASH (QUAD)
512Mbit (On Board)
M RAM (On Board)
DADF
SEE CH3
P14
IIT MOTOR
SEE CH6
P13
IIT CIS
SEE CH6
P15
IIT SENSOR
SEE CH6
P19
LPH Y
SEE CH6
P9
LPH M
SEE CH6
P10
LPH C
SEE CH6
P11
LPH K
SEE CH6
P12
J433
USB DEVICE
1
SEE CH34
PC PRINT
