Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-57
DC SC2020
General
6.3.8 NVM 746_Xfer 1 List
Version 1.1
6.3.8 NVM 746_Xfer 1 List
Table 1 NVM 746_Xfer 1 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
746-001 Primary Transfer Output Control SW 2 0 2 Control Switch of the Primary Transfer Output
0: Fixed Output, 1: Environment Control, 2: Vh Interlocking Con-
trol
-OO
746-002 Primary Transfer Output Fixed Output (63 Speed/BW Mode) 50 0 800 Output value when Primary Transfer Output Control is not exe-
cuted
0.1[A] O O
746-003 Primary Transfer Output Fixed Output (63 Speed/FC Mode) 200 0 800 Output value when Primary Transfer Output Control is not exe-
cuted
0.1[A] O O
746-004 Primary Transfer Output Fixed Output (126 Speed/BW Mode) 100 0 800 Output value when Primary Transfer Output Control is not exe-
cuted
0.1[A] O O
746-005 Primary Transfer Output Fixed Output (126 Speed/FC Mode) 400 0 800 Output value when Primary Transfer Output Control is not exe-
cuted
0.1[A] O O
746-006 Primary Transfer Output Heat Haze/Mock Heat Haze Correction
Run Environment
9 1 10 The run environment threshold value for Primary Transfer Output
Heat Haze/Mock Heat Haze Correction
-OO
746-007 Primary Transfer Output Heat Haze/Mock Heat Haze Area Cov-
erage Threshold Value
1 0 10 Primary Transfer Output Heat Haze Area Coverage Threshold
Value
1[%] O O
746-008 Primary Transfer Output Heat Haze/Mock Heat Haze Correction
Coefficient (63mm/s)
135 0 255 Primary Transfer Output Heat Haze/Mock Heat Haze Correction
Coefficient
1[%] O O
746-009 Primary Transfer Output Heat Haze/Mock Heat Haze Correction
Coefficient (126mm/s)
135 0 255 Primary Transfer Output Heat Haze/Mock Heat Haze Correction
Coefficient
1[%] O O
746-010 Resistance Detection Execution SW 1 0 1 Resistance Detection Execution Switch SW
0: Do not perform, 1: Perform
-OO
746-011 Secondary Transfer Fixed Output_Side 1 (When Resistance
Detection Not Performed)
200 0 600 The transfer bias output value when Resistance Detection is not
performed
10[V] O O
746-012 Secondary Transfer Fixed Output_Side 2 (When Resistance
Detection Not Performed)
200 0 600 The transfer bias output value when Resistance Detection is not
performed
10[V] O O
746-013 Secondary Transfer Resistance Detection Output (For Other than
Environment No. 9)
100 0 600 The resistance detection bias output value (for other than Environ-
ment No. 9)
10[V] O O
746-014 Secondary Transfer Resistance Detection Output (For Environ-
ment No. 9)
200 0 600 The resistance detection bias output value (for Environment No.
9)
10[V] O O
746-015 Secondary Transfer Output Group Correction Coefficient (For
Side 1)
100 0 255 Secondary Transfer Output Group Correction Coefficient (For
Side 1)
1[%] O O
746-016 Secondary Transfer Output Group Correction Coefficient (For
Side 2)
100 0 255 Secondary Transfer Output Group Correction Coefficient (For
Side 2)
1[%] O O
746-017 IBT Cleaner Initial Toner Band Density 100 0 100 IBT Cleaner Initial Toner Band Density 1[%] O O
746-018 IBT Cleaner Initial Toner Band Length in Process Direction 10 0 10 IBT Cleaner Initial Toner Band Length in Process Direction 1[mm] O O
746-019 IBT CLN Ban Process Direction Length 4 0 4 IBT Cleaner Curling Prevention Band Length in Process Direction 1[mm] O O
746-020 IBT CLN Band Concentration 60 0 100 IBT Cleaner Curling Prevention Band Density 1[%] O O
746-021 Heat Haze/Mock Heat Haze Prevention K Band Length in Pro-
cess Direction
80 0 100 Heat Haze/Mock Heat Haze Prevention K Band Length in Process
Direction
1[mm] O O
