05/2014
4-100
DC SC2020
8. Xero./Deve.
Version 1.1
Disassembly/Assembly and Adjustment
ADJ 8.1.6 Test Pattern Print
Action
• The Controller will perform each LUT setting for every output
pattern in Diag Mode Test Pattern.
Note
• Similar to the Customer Mode, [ON] is normally ON but will be
OFF if each switch setting is OFF. ADC Gradation Control LUT
will follow the [ADC Gradation Correction SW], TRC Manual
Adjustment LUT will follow the [TRC Manual Adjustment SW],
Auto Gradation Correction LUT will follow the [Auto Gradation
Correction SW] ON/OFF setting.
• IOT applies TRC Manual Adjustment OFF to ADC LUT for TRC
Manual Adjustment [OFF} of Auto Gradation Correction (Docu-
ment PG), and sends to the Controller from IOT when transfer-
ring to Key Operation Auto Gradation Correction Execution
Screen. The Controller side will apply the sent ADC LUT.
Test Pattern Sample
• PconPG (Procon ON/Procon ON)
Table 1 NVM List
Output Mode Output Pattern
LUT Setting
Screen
Potential
Control Disp ControlADC Gradation
Control TRC Manual Adjustment Calibration
Image Quality
TRC
DiagTest Pattern
Print
PconPG (Procon ON) ON ON ON ON Standard Screen Pcon Normal
PconPG (Procon OFF) ON ON ON ON Standard Screen Standard Normal
Y Up A4 5 copies ON ON ON ON Standard Screen Pcon Special
M Up A4 5 copies ON ON ON ON Standard Screen Pcon Special
C Up A4 5 copies ON ON ON ON Standard Screen Pcon Special
K Up A4 5 copies ON ON ON ON Standard Screen Pcon Special
Y Down A4 10 copies ON ON ON ON Standard Screen Pcon Special
M Down A4 10 copies ON ON ON ON Standard Screen Pcon Special
C Down A4 10 copies ON ON ON ON Standard Screen Pcon Special
K Down A4 10 copies ON ON ON ON Standard Screen Pcon Special
Calibration (Check PG) ON ON ON ON Calibration Specifica-
tion
Specified Screen
(4 types)
Pcon Normal
Cont Formation PG other than the
above
ON ON ON ON Standard Screen Pcon Normal
IOT Formation PG other than the
above
-- --- PconNormal
Key OperationCalibra-
tion
Execution screen
Calibration (Document PG) ON OFF OFF ON Calibration Specifica-
tion
Specified Screen
(4 types)
Pcon Normal
To Next Page
