05/2014
6-63
DC SC2020
General
6.3.10 NVM 749_LPH List
Version 1.1
6.3.10 NVM 749_LPH List
Table 1 NVM 749_LPH List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
749-001 LPH_DL_WAIT 400 0 1023 Download waiting time from LPH ROM to IBY in IBY Initial DL Sequence. 1[ms] O O
749-002 LPH_DL_FAIL_COLOR 0 0 15 Update (overwrite) the value during IBY Initial DL Sequence when No of Initial DL is 3 or
more.
(The (each) color generated from Fail on the 3rd initial DL will be saved. )
bit0: Y, bit1: M, bit2: C, bit3: K
-O O
749-003 LPH_DL_FAIL_POWER_COUNT 0 0 511 Count the No. of LPH_DL_FAIL_POWER occurred during IBY Initial Sequence. 1 [times] O O
749-004 LPH_IBY_STATUS_Y 0 0 128 During IBY Initial DL, store the IBY (Y) status register value only when Read is possible.
Return to default value when starting Initial DL Sequence.
If status register is Read multiple times after conducting Initial DL Process again, only
the 3rd value will be stored.
· bit0: CHECKSUM: Check result of Check sum 0=Check sum OK/1=Check sum NG)
· bit1: NO_ACK vs EEPROM ACK Error Flag (0=ack Normal/1=NO ack (ACK does
come back))
· bit2: BLANK_CHK Blank check result (0=BLANK Check OK/1=BLANK Check NG)
· bit3: VIF_ERR_FLAG VIDEOIF Error Flag (Refer to VIDEOIF Specification)(0=OK/
1=NG)
-O O
749-005 LPH_IBY_STATUS_M 0 0 128 During IBY Initial DL, store the IBY (M) status register value only when Read is possible.
Return to default value when starting Initial DL Sequence.
If status register is Read multiple times after conducting Initial DL Process again, only
the 3rd value will be stored.
· bit0: CHECKSUM: Check result of Check sum 0=Check sum OK/1=Check sum NG)
· bit1: NO_ACK vs EEPROM ACK Error Flag (0=ack Normal/1=NO ack (ACK does
come back))
· bit2: BLANK_CHK Blank check result (0=BLANK Check OK/1=BLANK Check NG)
· bit3: VIF_ERR_FLAG VIDEOIF Error Flag (Refer to VIDEOIF Specification)(0=OK/
1=NG)
-O O
749-006 LPH_IBY_STATUS_C 0 0 128 During IBY Initial DL, store the IBY (C) status register value only when Read is possible.
Return to default value when starting Initial DL Sequence.
If status register is Read multiple times after conducting Initial DL Process again, only
the 3rd value will be stored.
· bit0: CHECKSUM: Check result of Check sum 0=Check sum OK/1=Check sum NG)
· bit1: NO_ACK vs EEPROM ACK Error Flag (0=ack Normal/1=NO ack (ACK does
come back))
· bit2: BLANK_CHK Blank check result (0=BLANK Check OK/1=BLANK Check NG)
· bit3: VIF_ERR_FLAG VIDEOIF Error Flag (Refer to VIDEOIF Specification)(0=OK/
1=NG)
-O O
To Next Page
