05/2014
6-62
DC SC2020
6.3.9 NVM 747_Xfer 2 List
Version 1.1
General
747-018 Selected Secondary Transfer Segment Coefficient: Bn
(Side2)
0 0 6000 Selected Secondary Transfer Segment Coefficient: Bn (Side2) [X1] - O O
747-019 Selected Secondary Transfer Correction Coefficient: Pn
(Side 1)
0 0 255 Selected Secondary Transfer Correction Coefficient: Pn (Side 1) 1[%] O O
747-020 Selected Secondary Transfer Correction Coefficient: Pn
(Side 2)
0 0 255 Selected Secondary Transfer Correction Coefficient: Pn (Side 2) 1[%] O O
747-021 Secondary Transfer Reference Output (Side 1) 0 0 100000 Secondary Transfer Reference Output (Side 1) 10[V] O O
747-022 Secondary Transfer Reference Output (Side 2) 0 0 100000 Secondary Transfer Reference Output (Side 2) 10[V] O O
747-023 Secondary Transfer Final Output (Side 1) 0 0 600 Secondary Transfer Final Output (Side 1) 10[V] O O
747-024 Secondary Transfer Final Output (Side 2) 0 0 600 Secondary Transfer Final Output (Side 2) 10[V] O O
747-025 Secondary Transfer Final Output Digital Value (Side1) 0 0 255 Secondary Transfer Final Output Digital Value (Side1) - O O
747-026 Secondary Transfer Final Output Digital Value (Side2) 0 0 255 Secondary Transfer Final Output Digital Value (Side2) - O O
747-027 Non Paper Pass Section Density Fluctuation Countermea-
sure Band Accumulated PV Counter
0 0 6000 Non Paper Pass Section Density Fluctuation Countermeasure
Band Accumulated PV Counter
1 [PV] O O
747-028 Bleed Recovery Mode Time when Main Motor stopped dur-
ing the previous Job
0 0 4294967295 Save the time when Main Motor stopped during the previous Job - O O
747-029 IBT Reverse Rotation PV Counter 0 0 100000 IBT Reverse Rotation PV Counter 0.01 [PV] O O
747-032 Secondary Transfer Resistance Detection I Monitor Result
(Point 1)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 1) 0.1[A] O O
747-033 Secondary Transfer Resistance Detection I Monitor Result
(Point 2)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 2) 0.1[A] O O
747-034 Secondary Transfer Resistance Detection I Monitor Result
(Point 3)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 3) 0.1[A] O O
747-035 Secondary Transfer Resistance Detection I Monitor Result
(Point 4)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 4) 0.1[A] O O
747-036 Secondary Transfer Resistance Detection I Monitor Result
(Point 5)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 5) 0.1[A] O O
747-037 Secondary Transfer Resistance Detection I Monitor Result
(Point 6)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 6) 0.1[A] O O
747-038 Secondary Transfer Resistance Detection I Monitor Result
(Point 7)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 7) 0.1[A] O O
747-039 Secondary Transfer Resistance Detection I Monitor Result
(Point 8)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 8) 0.1[A] O O
747-040 Secondary Transfer Resistance Detection I Monitor Result
(Point 9)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point 9) 0.1[A] O O
747-041 Secondary Transfer Resistance Detection I Monitor Result
(Point 10)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point
10)
0.1[A] O O
747-042 Secondary Transfer Resistance Detection I Monitor Result
(Point 11)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point
11)
0.1[A] O O
747-043 Secondary Transfer Resistance Detection I Monitor Result
(Point 12)
0 0 4000 Secondary Transfer Resistance Detection I Monitor Result (Point
12)
0.1[A] O O
Table 1 NVM 747_Xfer 2 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
