Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
5-72
DC SC2020
98. Screws
Version 1.1
Parts List
98.1 Screws
Table 1
Item PART NO. Description
A 112W 27898 Pan Head Screw (M3x8)
B 113W 16088 Pan Head Screw (M2x10)
C 113W 20678 Screw (M3x6:White)
D 113W 20698 Round Screw (M3x6)
E 113W 20878 Screw (M3x8:White)
F 113W 21278 Screw (M3x12:White)
G 113W 27688 Pan Head Screw (M3x6:White)
H 115W 27878 Bind Head Tapping Screw (3x8:White) (P 1.4)
J 115W 28078 Bind Head Tapping Screw (3x10:White) (P 1.4)
K 116W 27478 Bind Head Screw (M3x4:White)
L 116W 27678 Bind Head Screw (M3x6:White)
M 153W 16288 Tapping Screw (M4x12:White)
N 153W 17688 Tapping Screw (M3x6:White)
P 153W 17888 Tapping Screw (M3x8:White)
Q 153W 27678 Bind Head Tapping Screw (M3x6:White) (P
1.06)
R 153W 27878 Bind Head Tapping Screw (M3x8:White) (P
1.06)
S 158W 27678 Screw (M3x6:White)
T 158W 27878 Screw (M3x8:White)
U 251W 26278 Plain Washer (5)
V 252W 27350 Nylon Washer (6) (t 0.5)
W 252W 27450 Nylon Washer (6) (t 1)
X 252W 29450 Nylon Washer (8) (t 1)
Y 271W 11250 Dowel Pin (1.6x12)
Z 271W 16050 Dowel Pin (2x10)
AA 271W 21050 Dowel Pin (2.5x10)
AB 271W 21060 Dowel Pin (2.5x10)
AC 271W 28260 Dowel Pin (3x12)
AD 271W 28850 Dowel Pin (3x20)
AE 285W 15851 Spring Pin (2x8)
AF 285W 16251 Spring Pin (2x12)
AG 285W 21851 Spring Pin (2.5x20)
AH 285W 28251 Spring Pin (3x12)
AJ 285W 28651 Spring Pin (3x16)
AK 354W 15278 E-Clip (2:White)
AL 354W 19278 E-Clip (2.5:White)
AM 354W 21254 KL-Clip (3)
AN 354W 21278 E-Clip (3:White)
AP 354W 24254 KL-Clip (4)
AQ 354W 24278 E-Clip (4:White)
AR 354W 26278 E-Clip (5:White)
AS 354W 27278 E-Clip (6:White)
AT 354W 29278 E-Clip (8:White)
AU 354W 27254 KL-Clip (6)
Table 1
Item PART NO. Description
