6.1.22 Alignment Specification
Version 1.1
General
*1: The center of the document must be set correctly at the center of the scan.
*2: Specified in the state where the Side Guide is set correctly.
*3: This specification should be applied on the assumption that it is adjustable by the operation on UI
after set up.
• DC Test Pattern (FX STP3600) (Figure 1)
Figure 1 j0ch61015
How to Measure
*1: For the reference value in the table, measure the length of the corresponding position on the FX
STP3600.
Perpendicularity (400 mm) +/-2.5mm
+/-2.8mm
- +/-3.4mm
+/-4.0mm
+/-2.1mm
Adjusted +/-1.7mm*3
+/-2.5mm
Adjusted +/-2.1mm*3
- +/-1.7mm +/-2.2mm
+/-2.0mm
Linearity (vertical) (400 mm span) 1.6mm
1.6mm
-2.0mm
2.0mm
0.8mm
0.8mm
-
-
0.8mm
-
0.5mm
0.5mm
Linearity (horizontal) (280 mm span) 1.2mm
1.2mm
-1.4mm
1.4mm
0.8mm
0.8mm
-- -
Linearity (diagonal) (280 mm span) 1.2mm
1.2mm
-1.4mm
1.4mm
0.8mm
0.8mm
-- -
Trapezoid Correction (400 mm) +/-2.2mm
+/-2.2mm
- +/-3.0mm
+/-3.0mm
+/-2.0mm
+/-2.0mm
- +/-0.7mm +/-1.8mm (400mm)
+/-1.5mm (280mm)
Table 1
Item
SYSTEM Spec *1 (Platen)
SYSTEM Spec (DADF)
IOT (non-consolidated) (Reference)
IIT (non-consolidated) DADF (non-consolidated)
Tray MSI *2 Tray MSI*2
Table 2
Measurement Item How to Measure
Lead Regi [mm] (P1 to P2) - Reference value *1
Side Regi [mm] (P7 to P8) - Reference value *1
Lead Skew (200 mm) [mm] (P5~P6) - (P3~P4)
Side Skew (400 mm) [mm] (P9~P10) - (P11~P12)
Horizontal R/E Precision (All area) [%] [(P8~P13) - 280]/280x100
Vertical R/E Precision (All area) [%] [(P2~P14) - 400]/400x100
Perpendicularity [mm] The shift between P14 and the perpendicular line that extends
from the intersection of the straight line connecting P4 and P6
and the line A.
Linearity (Vertical) (400 mm) [mm] The maximum shift between the intersections of the vertical line
B with the various horizontal lines and the straight line connect-
ing P10 and P12.
Linearity (Horizontal) (280 mm) [mm] The maximum shift between the intersections of the horizontal
line C with the various vertical lines and the straight line con-
necting P10 and P15.
Linearity (Diagonal) (280 mm) [mm] The maximum shift between the intersections of the diagonal
line D with the various lines and the straight line connecting P17
and P13, or the maximum shift of the intersections of the diago-
nal line E with the various lines and the straight line connecting
P8 and P18, whichever is larger.
Parallelism [mm] (P10~P12) - (P15~P16)
