05/2014
6-78
DC SC2020
6.3.11 NVM 750_Xero/Clean 1 List
Version 1.1
General
750-030 #M Total PV #126mm/s 0 0 4294967295 Counter by Process Speed PV O O
750-031 #C Total PV #126mm/s 0 0 4294967295 Counter by Process Speed PV O O
750-032 #K Total PV #126mm/s 0 0 4294967295 Counter by Process Speed PV O O
750-033 M/C Total Cycle 0 0 4294967295 M/C Total Number of Drum Rotation. Maintain the Total Cycle as M/C even CRU
is replaced
0.1[Cycle] O O
750-034 #Y Predicted Film Thickness 22000000 0 4294967295 The estimated film thickness value of the Drum is updated to the CRUM NVM [pm] O O
750-035 #M Predicted Film Thickness 22000000 0 4294967295 The estimated film thickness value of the Drum is updated to the CRUM NVM [pm] O O
750-036 #C Predicted Film Thickness 22000000 0 4294967295 The estimated film thickness value of the Drum is updated to the CRUM NVM [pm] O O
750-037 #K Predicted Film Thickness 22000000 0 4294967295 The estimated film thickness value of the Drum is updated to the CRUM NVM [pm] O O
750-038 #Y Low A/C Band ICDC Integrated Value 0 0 15000000 Low A/C Band ICDC Integrated Value ICDC O O
750-039 #M Low A/C Band ICDC Integrated Value 0 0 15000000 Low A/C Band ICDC Integrated Value ICDC O O
750-040 #C Low A/C Band ICDC Integrated Value 0 0 15000000 Low A/C Band ICDC Integrated Value ICDC O O
750-041 #K Low A/C Band ICDC Integrated Value 0 0 15000000 Low A/C Band ICDC Integrated Value ICDC O O
Table 1 NVM 750_Xero/Clean 1 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
