05/2014
6-128
DC SC2020
6.3.13 NVM 752_Process Control 1 List
Version 1.1
General
752-993 Last Setup Speed Stored Value_Mid/End[K][9] 0 0 1 Process Speed Stored Value after Mid/EndSetup is complete
0: 63mm/s, 1: 126mm/s
-OO
752-996 Disp Time Integrated Vaue_Refill[Y] 0 0 4294967295 Refill Determination Disp Integrated Value 1 [ms] O O
752-997 Disp Time Integrated Vaue_Refill[M] 0 0 4294967295 Refill Determination Disp Integrated Value 1 [ms] O O
752-998 Disp Time Integrated Vaue_Refill[C] 0 0 4294967295 Refill Determination Disp Integrated Value 1 [ms] O O
752-999 Disp Time Integrated Vaue_Refill[K] 0 0 4294967295 Refill Determination Disp Integrated Value 1 [ms] O O
Table 1 NVM 752_Process Control 1 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
