05/2014
6-165
DC SC2020
General
6.3.16 NVM 759_Registration Control 1 List
Version 1.1
6.3.16 NVM 759_Registration Control 1 List
Table 1 NVM 759_Registration Control 1 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
759-006 SR_EXP_LIMIT_SW 0 0 2 Side Regi Correction Exposable Width Limit Switch - O O
759-007 MOBCAP_ERR_FLG 0 0 65535 MOB Captcha Error Flag - O O
759-022 Detected Value of Belt Clean Surface during Vhigh
Setting [p=0]
0 0 1023 Detected Value of Belt Clean Surface during Vhigh Setting [p=0] - X O
759-023 Detected Value of Belt Clean Surface during Vhigh
Setting [p=2]
0 0 1023 Detected Value of Belt Clean Surface during Vhigh Setting [p=2] - X O
759-024 Detected Value of Belt Clean Surface during Vlow Set-
ting [p=0]
0 0 1023 Detected Value of Belt Clean Surface during Vlow Setting [p=0] - X O
759-025 Detected Value of Belt Clean Surface during Vlow Set-
ting [p=2]
0 0 1023 Detected Value of Belt Clean Surface during Vlow Setting [p=2] - X O
759-026 MOB LED Light Setting [p=0] 1000 0 2800 Calculates and sets up OnDuty_PWM [%] corresponds to MOB LED
Light Amount Setting [p=0]
-OO
759-027 MOB LED Light Setting [p=2] 1000 0 2800 Calculates and sets up OnDuty_PWM [%] corresponds to MOB LED
Light Amount Setting [p=2]
-OO
759-028 Belt Clean Surface Output Voltage [p=0] 0 0 1023 Belt Clean Surface Output Voltage [p=0] OUT Side MOB Sensor Belt
Clean Surface Output Voltage
-XO
759-029 Belt Clean Surface Output Voltage [p=2] 0 0 1023 Shown from Belt Clean Surface Output Voltage [p=2] IN Side MOB
Sensor Belt Clean Surface Output Voltage Elec
-XO
759-031 E Patch Detection Output Voltage [p=0] 0 0 1023 E Patch Detection Output Voltage [p=0] OUT Side MOB Sensor E
Patch Detection Output Voltage
-XO
759-032 E Patch Detection Output Voltage [p=2] 0 0 1023 E Patch detection Output Voltage [p=2] IN Side MOB Sensor E Patch
Detection Output Voltage
-XO
759-035 MOB GainResult 0 0 1 Set to 0 when starting MOB GainResultMOB GainResultFlag MOB-
Gain Correction Cycle. 0: Either IN/OUT or both of Final MOB Gain
Operation was unsuccessful (Fail occurred). 1: Both IN/OUT of final
MOB Gain Operation was successful (No Fail occurred).
-OO
759-036 Sensor Stability Fail Flag #OUT 0 0 1 Sensor Stability Fail Flag #OUT - O O
759-037 Sensor Stability Fail Flag #IN 0 0 1 Sensor Stability Fail Flag #IN - O O
759-038 Sensor LED Fail Flag #OUT 0 0 1 Sensor LED Fail Flag #OUT - O O
759-039 Sensor LED Fail Flag #IN 0 0 1 Sensor LED Fail Flag #IN - O O
759-040 Sensor TH Fail Flag #OUT 0 0 1 Sensor TH Fail Flag #OUT - O O
759-041 Sensor TH Fail Flag #IN 0 0 1 Sensor TH Fail Flag #IN - O O
759-081 Thresh Hold Level Voltage [p=0] 150 0 330 Thresh Hold Level Voltage [p=0] Outside MOB Sensor Thresh Hold
level Voltage (1.8V)
-OO
759-082 Thresh Hold Level Voltage [p=2] 150 0 330 Thresh Hold Level Voltage [p=2] Inside MOB Sensor Thresh Hold
Level Voltage (1.8V)
-OO
759-119 RC_Data_OverRange_Fail Flag 0 0 255 bit7: SSside1, bit6: SSside2, bit5: FSside1, bit4: FSside2, bit3:
PSKside1, bit2: PSKside2, bit1: -, bit0: -
OO
To Next Page
