Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-169
DC SC2020
General
6.3.17 NVM 760_Registration Control 2 List
Version 1.1
6.3.17 NVM 760_Registration Control 2 List
Table 1 NVM 760_Registration Control 2 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
760-001 LM_ENB_SW 1 0 1 Switch for enabling Fast Scan - O O
760-003 PSK_ENB_SW 1 0 1 Slow Scan Skew Correction Enable SW - O O
760-004 PSKoffset 0 -20 20 Sub Scanning Skew Offset 1pixel@600dpi O O
760-005 PM Special SW 0 0 1 Special Paper Type Support Switch
0: Do not perform, 1: Perform
-OO
760-006 PM_OFST_Special 0 -20 20 Special Paper Type Sub-scanning Magnification Offset 0.05[%] O O
760-008 SR_OFST1 0 -20 20 For Front Side Reg Offset IOT Delivery Adjustment 0.1[mm] O O
760-009 SR_OFST2 0 -20 20 For Back Side Reg Offset IOT Delivery Adjustment 0.1[mm] O O
760-015 IReCT_ENB_SW 1 0 1 IReCT Correction Enable SW - O O
760-017 PM_OFST_ORG[ProcessSpeedNum=0] -5 -20 20 PM_OFST_ORG_126 0.05[%] O O
760-018 PM_OFST_ORG[ProcessSpeedNum=1] -5 -20 20 PM_OFST_ORG_063 0.05[%] O O
760-019 Regicon Function Switch 1 0 1 RegiCon Function Switch (Upper switch of each function switch)
0: Do not perform, 1: Perform
-OO
760-020 MOB Sensor LED Light Quantity Adjustment
Function Switch
1 0 1 MOB Sensor LED Light Quantity Adjustment Function Switch
0: Do not perform, 1: Perform
-OO
760-021 CLRC Function Switch 1 0 1 ClosedLoopRegiCon Function Switch
0: Do not perform, 1: Perform
-OO
760-022 MOB-Gain Start Requirement Time 8 0 255 MOB-Gain Start Requirement Threshold Value Time Time O O
760-023 CLRC Start Time1 480 0 65535 CLRC TIme Regcon Operation Start Requirement Threshold Value Time1 minute O O
760-024 CLRC Start Temp1 20 0 255 Temperature difference amount from RC Last Temp1 0.1 [degree] O O
760-025 CLRC Start Temp2 255 0 255 Temperature difference amount from RC Last Temp2 0.1 [degree] O O
760-026 CLRC Start Temp_LPH_Dif 255 0 255 Temperature difference amount for standard color 0.1 [degree] O O
760-037 V high Target [p=0] 260 0 330 V high Target [p=0] - O O
760-038 V low Target [p=0] 30 0 330 V low Target [p=0] - O O
760-039 V Target [p=0] 220 0 330 V Target [p=0] - O O
760-040 Vout Rip Interval 30 1 100 Vout Rip Interval - O O
760-041 No. of Vout Rip 19 1 100 No. of Vout Rip - O O
760-042 No. of Permissible Vout NG 10 0 100 No. of Permissible Vout NG - O O
760-043 MOB Sensor Output Voltage Threshold Value
(For S1,S2)[p=0]
300 0 330 MOB Sensor Output Voltage Threshold Value (For S1,S2)[p=0] - O O
760-047 Th_Offset[p=0] 20 0 255 Value to offset the threshold value [p=0] - O O
760-048 Th_Offset[p=2] 0 0 255 Value to offset the threshold value [p=2] - O O
760-049 V high Target [p=2] 300 0 330 V high Target [p=2] - O O
760-050 V low Target [p=2] 30 0 330 V low Target [p=2] - O O
760-051 V Target [p=2] 250 0 330 V Target [p=2] - O O
760-052 MOB Sensor Output Voltage Threshold Value
(For S1,S2)[p=2]
300 0 330 MOB Sensor Output Voltage Threshold Value (For S1,S2)[p=2]+/-3V - O O
