Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-179
DC SC2020
General
6.3.20 NVM 767_Marking System 1 List
Version 1.1
6.3.20 NVM 767_Marking System 1 List
Table 1 NVM 767_Marking System 1 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
767-024 CRUM Mode Switch 0 0 1 Mode Change Switch
0: N/A, 1: Change to Xerox Mode
-O O
767-042 Color Mode Determination Switch 1 0 1 0: Maintain the latest status, 1: Follow the Cont instruction - O O
767-043 Latest Color Mode 1 0 1 0: BW, 1: 4C -O O
767-047 1st BTR Initialize Operation Switch 1 0 2 0: Do not perform.
1: Only perform when Power On.
2: Perform in Power On, Interlock Close, Sleep Recovery.
-O O
767-059 Lead Image Loss Amount 40 40 255 The amount of image erasure at the Lead Edge in the paper feed direction for the
printed image
0.1[mm] O O
767-060 Side Image Loss Amount 20 20 255 The amount of image erasure at the Lead Edge in the paper feed direction for the
printed image
0.1[mm] O O
767-061 End Image Loss Amount 20 20 255 The amount of image erasure at the Rear End in the paper feed direction for the printed
0.1[mm] O O
767-127 Lead Edge Erase Amount 40 40 255 Lead Edge Erase Amount 0.1[mm] O O
767-128 Side Erase Amount 20 20 255 Side Edge Erase Amount 0.1[mm] O O
767-129 Tail Edge Erase Amount 20 20 255 Tail Edge Erase Amount 0.1[mm] O O
