05/2014
6-271
DC SC2020
General
6.5.5 Hardware Key Test
Version 1.1
• The [Start] button and [<-] button/[Delete] key do not do anything if any memory check is in
progress.
• Return to the Panel Diag Menu using the [<-] button/[Delete] key.
6.5.5 Hardware Key Test
6.5.5.1 Function Explanation
• Perform a test to see if the Hardware Key will be detected by pressing it.
• Enable the detecting diagnosis of the Hardware Key when it is simultaneous pressed as well.
• The Hardware Key character string displayed on the LCD will change its color while the Hardware
Key is being pressed. By releasing the Hardware Key, the character string color will remain changed
indicating that it has been pressed.
• The Hardware Key used in tests are as follows:
Table 1 Hardware Key List
Hardware Key Display Name
Services Services
Job Status Job Status
11
22
33
44
55
66
77
88
99
00
**
##
CC
Redial/Pause Redial
Pause
Clear All Clear All
Stop Stop
Start Start
Energy Saver Energy
Saver
To Next Page
